21
Operation
(4) Pressing Fan key or Mode key can both exit swing function,
with no order sending. When Fan or Mode key is pressed
again, the order will be sent. If the present angle is conrmed,
pressing SET key will exit the swing function. In the adjustment
process, if there is no key pressed for 10s, swing function
will be exited, and swing angle will execute the nal adjusted
angle. In the adjustment process, pressing the ON/OFF key to
power off the wired controller directly, and swing angle is the
nal adjusted swing angle.
