Parts and Functions

Clock Set

When unit is started for the first time and after replacing batteries in

remote controller, clock should be adjusted as follows:

3. After time setting is confirmed, press SET, "AM" or "PM" stop flashing,

while clock starts working.

2. Press or to set correct time. Each press will increase or decrease

1 min. If the button is kept depressed, time will change quickly.

1. Press CLOCK button,"AM" or "PM" flashes.

Remote controller's operation

When in use, put the signal transmission head directly to the receiver hole on the indoor unit.

The distance between the signal transmission head and t

he receiver hole should be within

7m without any obstacle as well.

Don't throw or knock the remoter controller.

When electronic-started type fluorescent lamp or change-over type fluorescent lamp or

wireless telephone is installed in the room, the receiver is apt to be disturbed in receiving

the signals, so the distance to the indoor unit should be shorter.

Loading of the battery

Load the batteries as illustrated right

2 R-03 (7#) batteries

Remove the battery cover:

Slightly press" "area and push down the cover

as illustrated.

Load the battery:

Be sure that the loading is in line with the "+" / "-".

request as illustrated on the bottom of the case.

Put on the cover again.

Confirmation indicator:

After pressing power ON/OFF, if no display, reload the batteries.

Remove the batteries in case unit won't be in usage for a long period. If there are any display

after taking-out, just need to press reset key.

Note:

Full display or unclear display during operation indicates the batteries have been used up.

Please change batteries.

Used two new same-typed batteries when loading.

If the remote controller can't run normally during operation, please remove the batteries and

reload several minutes later.

Hint:
