6
Parts and Functions
NOTE:(1) The following functions and related displays are not available:
(2) Cooling only unit do not have functions and displays related with heat
ing
.
.
Operation mode
AUTO
FAN
COOL DRY
Remote controller
Display board
HEAT
15
16
Singal rece
i
ver hole
When the remote controller appears abnormal,
use a sharp pointed article to press this button
to reset the remote controller normal.
1.RESET
Used to select TIMER ON, TIMER OFF,
TIMER ON-OFF.
3. TIMER button
Used to set correct time.
4. CLOCK button
Used to select sleep mode.
5. SLEEP button
6. MODE button
AUTO COOL DRY FAN HEAT
Used to set clock and timer setting.
7. HOUR button
Used to set healthy operation.
8. HEALTH button
Used for unit start and stop.
9. ON/OFF button
10. TIMER ON display
11. FAN SPEED display
LOW HI
MED AUTO
12. LOCK display
13. SWING UP/DOWN display
14. SLEEP display
15. HEALTH display
Used to select your desired temperature.
16. Operation mode display
18. POWER/SOFT display
19. Left/right air flow display
Remote controller: to display the TEMP. setting.
20. TEMP display
21. TIMER OFF display
22. TIMER display
23. TEMP button
Used to select fan speed: LOW,MED, HI, AUTO.
24. FAN button
Used to set the health airflow mode.
25. HEALTH AIRFLOW button
26. SWING UP/DOWN button
Used to select up or down air sending direction.
27. SWING LEFT/RIGHT button
Used to select left/right air flow.
Used to confirm timer and clock settings.
28. SET button
29. POWER/SOFT button
Used to lock buttons and LCD display. If pressed, the
other buttons will be disabled and the lock condition
display appears. Press it once again, lock will be
canceled and lock condition display disappears.
30. LOCK
Every time the button is pressed,display changes
as follows:
32. Ambient temp.display
31
21
30
28
19
POWER
SOFT
BLANK
17.Singal sending display
2.LIGHT button
Control the lightening and extinguishing of
the indoor LED display board.
When receiving the remote control signal, display the set
temperature and in the rest time the room temperature is
displayed and this room temperature is only for reference.
16
16
31
