Haier AS072AZNDA [10/20] Operation
![Haier AS072AZNDA [10/20] Operation](/views2/1815677/page10/bga.png)
Unit will run in selected mode.
Stop display at " " AUTO or " " FAN.
Operation
Enjoy yourself by just a gentle press.
(1) Unit start
(2) Select operation mode
(3) FAN
(4) Unit stop
AUT
AUT
AUT DR HEA FA
Press ON/OFF button, unit starts.
Previous operation status appears on
display.
(Not Timer setting)
Press MODE button. For each press,
operation
Press FAN button. For each press, fan speed
changes
Remote controller can memorize settings in each operation mode. To run it
next
time just select the operation mode and it will start with the previous setting.
Hints
Auto run, Fan operation
COOL
Unit will run at selected fan speed.
Note:AUTO is not available in FAN mode.
Adjust air flow direction if necessary, referring to page10.
LO
MED
HI
Press ON/OFF button.
Only time remains on LCD.
All indicators on indoor unit go out.
Vertical flap closed automatically.
TEMP
SWING
MODE
CLOCK
SLEEP
SET
LOCK
RESET
TIMER
FAN
OFF
ON
AUTO
AM
1
3
4
2
