Haier AD42NAMBEA(ECO) [7/19] Parts and functions
![Haier AD42NAMBEA(ECO) [7/19] Parts and functions](/views2/1815692/page7/bg7.png)
Parts and Functions
6
Air outlet
Air inlet
Air outlet
Air inlet
AD182AMBEA(ECO)
AD242AMBEA(ECO)
AD28NAMBEA(ECO)
AD36NAMBEA(ECO)
AD42NAMBEA(ECO)
