When the unit have the Return air box (see the following picture)
when shipping from the factory and they are of back-side return air
type. During the installation, the unit also can be changed to a Down-
side Return air according to the user's need.
NOTE
Electrical control box
1
3
4
5
2
1.OUTLET
2.CONTROL PANEL
3.INLET
4.FILTER ( inside )
5.OUTLET
5.3 Duct type AD***XLEAA
5.4 Console Type AF***XCEAA
Chff^j\bZe Abj Chg]blbhg^j
z 13 z
