![Haier AB25S2SC1FA [8/182] Specification](/img/pdf.png)
Haier AB25S2SC1FA [8/182] Specification
![Haier AD25S2SS1FA [8/182] Specification](/views2/1816520/page8/bg8.png)
6
Item Model AB25S2SC1FA
Function —— Cooling Heating
capacity W 2600 3200
sensible heat ratio W 0.71 /
Dehumidifying capacity 10-³xm³/h 1.0
indoor unit
power supply 1PH, 220-240V~, 50/60Hz
Fan
Type × Number —— centrifugal*1
Speed(H-M-L) r/min 690/620/560/500
Fan motor output/input power W 10/15
Air-ows (H/M/L) m³/h 620/520/450/350
Heat exchanger
Type / Diameter mm inner grooved pipe/
￠
7.0
Row —— 1
Total area m² 0.272
Temp.scope
℃
2.0-7.0
Dimension
(LxWxH)
External mmxmmxmm 570*570*260
Package mmxmmxmm 718*680*380
Drainage pipe (material,I.D/O.D) mm PVC 26/32
control type(Remote/Wired) Remote YR-HBS01(O) or Wired YR-E17(O)
Fresh air hole dimension mm 95
Electricity Heater kW none
Noise level(H-
M-L)
Sound power level dB(A) 52
Sound pressure level dB(A) 36/33/30/27
weight(Net/Shipping) kg/kg 17/20
panel
panel model(color) PB-700IB(White)
Dimension
External(L*W*H) mmxmmxmm 700*700*60
Package(L*W*H) mmxmmxmm 740*750*115
Weight(Net/Shipping) kg/kg 2.8/4.8
Piping
Refrigerant Type R32
Pipe
Liquid mm Φ6.35(1/4)
Gas mm Φ9.52(3/8)
Connecting method Flared
Norminal condition: indoor temperature (cooling): 27
℃
DB/19
℃
WB, indoor temperature (heating): 20
℃
DB
Outdoor temperature(cooling): 35
℃
DB/24
℃
WB, outdoor temperature(heating): 7
℃
DB/6
℃
WB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound
intensity meter.
1. Specification
