Haier ESA410K [14/24] Domestic air conditioner
![Haier ESA412K-L [14/24] Domestic air conditioner](/views2/1818801/page14/bge.png)
ESA412K Installation and Accessory Parts
Domestic Air Conditioner
13
Parts
Tools
Check that all parts are included in parts package.
■
Phillips head screwdriver
■ Flat-blade screwdriver
■ Scissors
■ Level
■ S
ocket wrench and sockets
■ Tape measure
■
Cordless drill and 1/8” bit
■ Pencil
■ Pliers
■ Adjustable wrench
A
B
C
D
E
F
G
H
I
ON/OFF
MODE
SPEED
TIMER
TEMP/TIME
TEMP/TIME
A. Top channel
B. Foam seal
C. Side brackets (2)
D.Window lock bracket
E.
c” screws :
ESA410K,ESA410K-L(4)
ESA412K,ESA412K-L(4)
ESA410K-T,ESA410K-E(4)
ESA406K,ESA406K-L(3)
ESA408K,ESA408K-L(3)
ESA406K-T,ESA408K-T(3)
ESA408K-E(3)
F. c ” screws (9)
G. Side curtains (2)
H. Side curtain
frames (2)
I. Remote control
