Domestic Air Conditioner
12
Installation and Accessory Parts
ESA412K
Top View
Bottom View
1. Insert the foam seal behind the top of the lower window sash and against the glass of the upper window.
"
#
A. Top of lower window sash
B. Foam seal
2. Place the window lock bracket as shown. Use a
Complete Installation
c” drill bit to drill a starter hole through the hole in the window lock
bracket and into the upper window.
3. Attach the window lock bracket to the upper window with one
©c” screw to secure the window in place.
4. Plug into a grounded 3 prong outlet.
5. Press RESET on the power supply cord. See “Electrical Requirements.”
