DOD LS400W [2/2] Image quality will be better while recording in a sunny day but please note in backlight position the image will be darker it s the normal reaction while image sensor face the light s...

Installation and Fixation

Software Operation

Notes

System Settings

Recording Settings

Video Playback

Video-Play Operation

1.After stopped recording, press MODE to enter the video-play

mode.

2.Press UP or Down to select the desired video to play.

3.Press CONFIRM to start playing video.

4. Press CONFIRM again to pause the video.

Delete Video

1.After stopped recording, press MODE to enter the video-play

mode.

2.Press UP or Down to select the desired video to delete.

3.Press MENU, enter the menu to delete the video or delete all.

Play on Computer

Recommended PC requirements for 1080P 30fps video playing:

1.intel Core 2 Duo 2.0GHz or above CPU

2.2G or above DDRII RAM

3.Graphic card supports DirectX 10 or above

Power On/Off

Product Structure

Switch On

1.Please insert the memory card into the SD Card Slot with the

specified direction, and then use the bracket to install the device

inside the car.

2.When using the bracket, please choose the position carefully. Do

not place the device in the position that blocks the driver's sight

or affects the work of the airbags.

3.If there is any splotch, fingerprints or other kinds of smudginess

on the windshield, please wipe clean it before installing.

Please connect the vehicle cigarette lighter and start the engine, the

device will be switched on immediately.

When car engine stooped or car power disconnected, the device will

shutdown in 10 seconds automatically.

1.For the users whose vehicle cigarette lighter keeps power

supplying after the engine stopped, please unplug the car

charger before leaving the vehicle.

2.Please use Class 6 or above Micro SD card

1.Insert the memory card

2.Connect the car charger into the vehicle

cigarette lighter and the device

3.Start the vehicle.

4.The device be turned on, and start

recording automatically.

Recording image

Standby Image

Hardware Installation Guide

Thank you for purchasing Our company product, please

following the instruction to use the device correctly.

Our company products are made of top materials to provide

the best quality product with the best image quality to all

customers.

Recording notes

1. Recording in a car without film on windshield can ensure the

best image recorded.

2. Please keep the windshield clean to prevent bad influence

on image quality.

3. If windshield wiper can't clean the windshield, please

replace it with a new one, or the image quality in the rainy

day will be influenced.

4. Image quality will be better while recording in a sunny day, but

please note in backlight position the image will be darker, it's

the normal reaction while image sensor face the light straightly.

1 2 3

4 5 6 7 8

11 12

After stopped recording, press MENU to enter the recording

settings.

Toggle on the WDR function.

Resolution Set the recording resolution.

Exposure：Set the exposure value.

White Balance: Adjust for ambient light.

Record Audio：Toggle on or off the sound recording function.

Date Stamp：Toggle on or off the data stamp function.

Loop recording：Set the video length in recording cycle mode, or

toggle off record cycle function.

Gsensor：Set the sensitivity level of the G-sensor file protection .

Motion Detection：Toggle on or off the motion detection recording

function.

License plate display: can display the registration number on the

video.

Password setting: Set the system operation and to protect the

password file security.

Image Rotation: Set the image rotation feature on or off.

WDR：

：

After stopped recording, press MENU twice to enter the system

setup.

Format： Format the memory card; please backup your data before

formatting.

Language：Support multiple languages; you can choose the

language according to your preferences.

Date/Time： the system time.

Frequency： Support 50Hz and 60Hz .

IR LED： Switch on or off LED light function.

Beep Sound：Switch on or off the system beep indicator.

Screen saver ：Set the screen automatic off time, or set it

as always on.

TV Mode：You can toggle between NTSC and PAL when in video

output mode.

Version： Check the system version number.

Default Setting：Reset all the settings to the default state.

Set

1.WDR works all time

2.Recording image

3.Recording mode

4.Resolution

5.Loop recording in 3 minutes length

6.Exposure

7.Microphone

8.Power connected

9.Motion Detection

10.Time

11.Memory Card icon

12.Recording time

13.Date

14.White Balance

6. After the machine high and low temperature testing; But in

order to ensure a longer life, summer heat inside the car,

such as the machine without work, the proposed move to

the shade.

5. In order to present a better video and audio quality, we

suggest using the following player software: Storm video,

windows Media Player, QuickTime Player.
