DOD LS430 [2/2] Please connect the vehicle cigarette lighter and start the engine the device will be switched on immediately when the engine stoppedor the vehicle power supply be removed the device will shutdown automatically
![DOD LS400 [2/2] Please connect the vehicle cigarette lighter and start the engine the device will be switched on immediately when the engine stoppedor the vehicle power supply be removed the device will shutdown automatically](/views2/1081943/page2/bg2.png)
SD
Hardware Installation Guide
Installation and Fixation
Software Operation
Notes
DOD Opening
System Settings
Recording Settings
Video Playback
Video-Play Operation
1.After stopped recording, press MODE to enter the video-play
mode.
2.Press UP or Down to select the desired video to play.
3.Press CONFIRM to start playing video.
4. Press CONFIRM again to pause the video.
Delete Video
1.After stopped recording, press MODE to enter the video-play
mode.
2.Press UP or Down to select the desired video to delete.
3.Press MENU, enter the menu to delete the video or delete all.
Play on Computer
It is recommended to play the video by free software VLC PLAYER.
Please go to http://www.videolan.org/vlc/ to download and install
VLC Player.
Recommended PC requirements for 1080P 30fps video playing:
1.intel Core 2 Duo 2.0GHz or above CPU
2.2G or above DDRII RAM
3.Graphic card supports DirectX 10 or above
After stopped recording, press MENU to enter the recording
settings.
Record Cycle Set the video length in recording cycle mode, or
toggle off record cycle function.
Sound Recording：Toggle on or off the sound recording function.
Motion Detection：Toggle on or off the motion detection
recording function.
G-sensor：Set the sensitivity level of the G-sensor file protection .
White Balance：Process adjustment by environment light sources.
Resolution：Set the recording resolution.
Effect：Present different image colors with different effects
Driver Fatigue Warning：Toggle on or off the driver fatigue
warning function.
GPS Logger：toggle on or off the GPS logger function.
GPS Speed Warning：Set the GPS over speed warning in
kilometers or switch off the GPS over speed warning function.
HUD：Set the standby time to toggle on or off the standby
speed display function.
Time Zone：Please set your local time zone in accordance with
the Greenwich Mean Time.
：
★
★
★
★
★Only applicable to the built-in GPS module models
After stopped recording, press MENU twice to enter the
system setup.
Beep Switch on or off the system beep indicator.
Auto Power Off Set the automatic shutdown time after the
power disconnected or keep the device working until the
battery run out.
LCD Off：Set the screen automatic off time, or set it as always
on.
TV Mode：You can toggle between NTSC and PAL when in
video output mode.
Format： Format the memory card; please backup your data
before formatting.
Default Setting：Reset all the settings to the default state.
Language：Support multiple languages; you can choose the
language according to your preferences.
Frequency：Support 50Hz and 60Hz.
Date/Time：Set the system time.
Version：Check the system version number.
：
：
Power On/Off
Product Structure (Including Hotkey)
Switch On
Recording image
10
11 12
13 14
16
15
17
18
3
5
1
4
6
9
2
7
8
10.Micro-SD Card Slot
11.USB/Vehicle Charger Power Supply Port
3.UP/Zoom in
5.MENU Key
4.DOWN/Zoom out
7.LED lamp / SOS Emergency File
Lock
8.EV Adjustment
9.2.7-Inch TFT Display Screen
15.HDMI Output Jack
14.Video Recording/Camera/Confirm
13.Power switch
16.Reset key
2.Microphone
1.Indicator
12.AV Output Jack
17.LED lamp
18.Speaker
6.MODE Switch/ Mute Mode in Video
Recording
1.Please insert the memory card into the SD Card Slot with the
specified direction, and then use the bracket to install the device
inside the car.
2.When using the bracket, please choose the position carefully. Do
not place the device in the position that blocks the driver's sight
or affects thel work of the airbags.
3.If there is any splotch, fingerprints or other kinds of smudginess
on the windshield, please wipe clean it before installing.
Please connect the vehicle cigarette lighter and start the engine, the
device will be switched on immediately.
When the engine stoppedor the vehicle power supply be removed,
the device will shutdown automatically.
1.For the users whose vehicle cigarette lighter keeps power
supplying after the engine stopped, please unplug the car
charger before leaving the vehicle.
2.Please use Class 6 or above Micro SD card
1.Insert the memory card
2.Connect the car charger into the vehicle
cigarette lighter and the device
3.Start the vehicle.
4.The device be turned on, and start
recording automatically.
LS430/400
