Haier HTWR08XCK [10/20] Part s and functions

6.Parts and Functions

HTWR08XCK Partd and Functions

Domestic Air Conditioner

1. Press MODE until you see the indicator light glow for the desired setting.

2. Choose Fan, Cool, Energy Saver or Dehum.

■ Fan—Only the fan runs. Press SPEED to select High, Med or Low fan speed. The display shows the

current room temperature.

■ Cool—Cools the room. Press SPEED to select High, Med or Low fan speed. Press the TEMP/TIME up

or down arrow button to adjust the temperature.

■ Energy Saver—Fan runs only when cooling is needed. Press SPEED to select High, Med or Low fan

speed. Because the fan does not circulate the room air continuously, less energy is used, but the room

air is not circulated as often.

■ Dehum—Dries the room. The air conditioner automatically selects the temperature.

NOTE: Dehum mode should not be used to cool the room.

FAN

COOL

ENERGY

SAVER

DEHUM

MODE

Mode

1. Press FAN SPEED until you see the indicator light glow for the desired setting.

2. Choose High, Med or Low.

■ High—for maximum cooling

■ Med—for normal cooling

■ Low—for minimum cooling

HIGH

MED

LOW

SPEED

Fan Speed

■ Press the TEMP/TIME up arrow button to raise the temperature. Each time you press or hold the TEMP/TIME

up arrow button, the temperature will go up 1ºF until it reaches 86°F (30°C).

NOTE: After 5 seconds, the display will show the current room temperature.

Temperature

In Dehum mode,Please do not operate the speed button.

TEMP/TIME
