Capacity 1.5 to 5 Tons
Models: HC1891VAR HC2491VAR
HC3091VAR HC3691VAR
Installation & Operation Manual
Central Air Conditioner
The information contained in this booklet is subject to change without notice.
HC4291VAR HC4891VAR
HC6091VAR
Содержание
- Central air conditioner 1
- Installation operation manual 1
- Warning 2
- Table of content 3
- Introduction 4
- Nomenclature for model number 4
- Specification 4
- Model hc18 6091var table 1 5
- Equipment protection from environment 6
- Installation 6
- Unit inspection 6
- Do not allow the vapor line and liquid line to touch together this would cause an undesirable heat transfer resulting in capacity loss and increased power consumption 8
- Figure 3 8
- Line insulation suction line requires insulation in order to prevent condensation from forming on the piping and to prevent heat gain caused by surrounding air generally 3 8 wall thickness of armflex or equivalent is satisfactory in severe application hot high humidity areas greater thickness may be required apply the line insulation by sliding it on the sealed tuing before cutting and making connections 8
- Liquid line does not necessarily need insulation however if they are exposed to high ambient temperatures i e kitchen boiler rooms hot attics rooftop surface then they should be insulated make sure to use the proper size tubing for the liquid line to prevent liquid refrigerant flashing to a vapor within the liquid line 8
- Electrical wiring 11
- System startup 12
- Miscellaneous 13
- Operation 13
- Air conditioner wiring diagram 15
- Color codes bk black bl blue gy gray br brown gr green or orange pu purple rd red vi violet wh white yl yellow 15
- Component codes bcr blower control relay bcap run capacitor blower motor cc compressor contactor cch crankcase heater optional chs crankcase heater switch optional cmpr compressor hps high pressure switch lps low pressure switch ibm indoor blower motor ofm outdoor fan motor rcap run capacitor compressor rvs reversing valve solenoid stcap start capacitor optional strly start relay optional strth start thermistor optional tran transformer 230 208 selectable 15
- Compressor 15
- Compressor protect 3 min time delay 15
- Ha cool off heat 15
- Hc18 6091var 15
- L2 gnd 15
- Line voltage factory standard field installed optional low voltage factory standard field installed optional 15
- Optional low high pressure switches 15
- Use copper conductors only warning cabinet must be permanently grounded and all wiring to conform to i e c n e c c e c c l c and local codes as applicable replacement wire must be the same gage and insulation type as original wire 15
- Vac common 15
