Commercial Air Conditioner
Model: AU28/342FHAIA,
AU522FIAKA, AU52,60NFIAKA
-13-
AE182FCAMA AE212FCAMA
Cooling capacity Btu/h 18000 21000
Heating capacity Btu/h 20000 24000
Cooling capacity W 5000 6000
Heating capacity W 6000 7000
Dehumidifying capacity
10‐³×m³/h
-- --
Power source N, V, Hz
1PH 220V-230V~ 50HZ 1PH 220V-230V~ 50HZ
Refrigerant
R22 R22
Noise level(H/M/L) dB(A) 37/36/34 37/36/34
Type × Number
centrifugal fan×2 centrifugal fan×2
Air-flow(H-M-L) m³/h 1000/--/-- 1000/--/--
starting mothod
-- --
Heat exchanger
Refrigerant control method
External
mm×mm×mm
1124×450×225 1124×450×225
shipment
mm×mm×mm
1272×526×288 1272×526×288
Net kg / kg 25/27 25/27
Liquid mm
9.52 9.52
Gas mm
15.88 15.88
Suited area
m
2
-- --
Controller type
wired controller wired controller
AE242FCAMA
Cooling capacity Btu/h 24000
Heating capacity Btu/h 27000
Cooling capacity W 7100
Heating capacity W 8000
Dehumidifying capacity
10‐³×m³/h
--
Power source N, V, Hz
1PH 220V-230V~ 50HZ
Refrigerant
R22
Noise level(H/M/L) dB(A) 39/37/35
Type × Number
centrifugal fan×3
Air-flow(H-M-L) m³/h 1500/1200/900
starting mothod
--
Heat exchanger
Combination of wave
cranny radiation fin and
Refrigerant control method
Capillary + Electronic
expansion valve
External
mm×mm×mm
1253×450×225
shipment
mm×mm×mm
1520×526×288
Net kg / kg 42/44
Liquid mm
9.52
Gas mm
15.88
Suited area
m
2
--
Controller type
wired controller
Item model
Fan
Fan
Dimension(L×W×H)
Dimension(L×W×H)
Piping
Dimension(L×W×H)
Weight(unit/panel)
Piping
Item model
Dimension(L×W×H)
Combination of wave cranny radiation fin and
Electronic expansion valve
Weight(unit/panel)
water diameter (mm)
16
16
water diameter (mm)
16
