8. Electrical Control Functions
8.1 Outdoor control principle:
No Item AU282FHAIA AU522FIAKA AU52NFIAKA
1. Startup period in cooling
mode: high
2. Cool, Dry mode:
●Current state is Fan OFF
mode:
TC＞21℃: low speed
● Current state is low
speed:
TC＞30℃, med speed
TC＜15℃, fan off
● Current state is med
speed:
TC＞42℃, high speed
TC＜22℃, low speed
● Current state is high
speed:
TC ＜ 39 Current state is
med speed:
1. Startup period in cooling
mode: high
2. Cool, Dry mode:
● Current state is Fan OFF
mode:
TC＞37℃: low speed
●Current state is low speed:
TC＞50℃, med speed
TC＜30℃, fan off
●Current state is med speed:
TC＞47℃, high speed
TC＜40℃, low speed
●Current state is high speed:
TC＜41℃, med speed
●In low speed:
TC＜40℃, lower fan off
TC＞42℃, lower fan startup
1. Startup period in cooling
mode:
TA＞16℃, high speed
TA≤16℃, low speed
2. Cool, Dry mode:
●TA＞32℃, high speed
●15℃≤TA＜31℃:
TC＞45℃, high speed
40 ℃＜TC ＜ 44 ℃ , med
speed
TC＜39℃, low speed
●TA＜15℃:
TC＜30℃, fan off
TC＞50℃, low speed
●In low speed:
TC＜36℃, lower fan off
TC＞38℃, lower fan startup
1
Fan motor
control
1. Startup period in heating:
High speed
2. Running state in heating:
●TA＞17℃:
running units capacity≤
1HP, low speed will be
ON and OFF in turns.
●Other condition:
TE＜7℃, high speed
TE＞10℃, low speed
1. Startup period in heating:
High speed
2. Running state in heating:●
TA＞17℃:
running units capacity ≤
1HP, low speed will be ON
and OFF in turns.
●Other condition:
TE＜7℃, high speed
TE＞10℃, low speed
3. TE＞14℃, lower fan off
TE＜12, lower fan startup
1. Startup period in
heating:
TA≥20℃, low speed
TA＜20℃, high speed
2. Running state in
heating:
●TA＞17℃:
running units capacity≤1
HP, low speed will be ON
and OFF in turns.
running units capacity ＞
1HP, low speed
● 17 ℃＞TA ＞ 15 ℃ , low
speed
● 14 ℃＞TA ＞ 10 ℃ , med
speed
●TA＜9℃, high speed
2 EEV In COOL, DRY, DEFROST state, EEV will open fully with 480 pulse.
Commercial Air Conditioner
Model: AU28/342FHAIA,
AU522FIAKA, AU52,60NFIAKA
-76-
