INSTALLATION

The air exhaust fan shall only be installed, connected to electrical mains and commissioned

for use by qualified personnel in accordance with applicable laws!

Assembly

Precisely choose the installation location of the air exhaust fan.

•

Prepare the power cable to make the power supply line. Use NYM-O 2x1.5 mm² (H07V-K 2x1.5 mm²) or NYM-O 3x1.5 mm² (H07V-K 3x1.5 mm²), maximum outer

diameter 8 mm, according to the optional accessories provided (does not apply to the models with the supply cable attached).

•

Run the power cable in double insulation through the grommet (8). Enough of the power cable must enter the air exhaust fan to facilitate connection of the cores

to the power input terminals on the board (5). The minimum length of the cable in the external insulation is 10 mm (inside the chamber).

Before fastening the air exhaust fan to the installation substructure: remove all foreign objects from the inside of the air exhaust fan; check that the fan rotor

turn freely by hand; check that there is enough clearance for the opening motion of the check damper closure on the air exhaust fan outlet end (the check

damper is sold separately);

It is recommended to connect the air exhaust fan to the air exhaust ductwork with a flexible stub pipe!

•

Align the air exhaust fan housing (7) with the holes and drive the wall bolt plugs into the holes.

CAUTION! While mounting at the wall, place the air exhaust fan so that the cable grommet is at its bottom!

•

erify that the power cable cores are held tight by the terminals.

•

Check the air exhaust fan for the soundness of mounting and correct electrical installation.

•

Adjust the operating parameters as follows:
