Maintenance

4. Install air filter

5. Close air inlet grille

Clean the air inlet grille

1. Open air inlet grille

2. Remove air filter

3. Remove the air inlet grille

4. Clean

Notice

Do not use the hot water over 50 C to clean

to avoid discoloration or deformation.

Use soft brush, water and neutral detergent to clean,

then throw the water off.

Instruction

[ When there is too much dust ]

Use ventilation fan or directly spray the detergent special for kitchen

ware on the air inlet grille, 10 minutes later use water to clean.

5. Install air inlet grille

(1)Put the air filter into those extruding parts at the top of the air inlet grille.

(2)Draw the handles at the back of the air inlet grille inwards to fix the air filter.

Referring to procedure 1.

Pull the two handles at the same time, slowly draw them

out. (when closing it, the procedure is reversed.)

Referring to ìClean the air filterî.

Referring to procedure 3.

6. Install the air filter

Referring to ìClean the air filterî

Referring to procedure 1.

7. Close air inlet grille

Open the air inlet grille for 45 , the lift it up.

Open
