Quick Installation Guide
Gigabit Switch
Suitable for: S505G & S808G
Checking Package Contents
Before Installation
1* 5/8-Port 10/100/1000Mbps Switch
1* Power Adapter
1* Quick Installation Guide
S808G
LED Indicators
LAN
PWR
LED Indicator
Status
on
off
on
off
Indication
Lights Orange when the switch is receiving power
Powered off
Connected to network lights on, data transmission
blinks Orange
Not connected
Appearance
Hardware Installation
Specifications
Interface
Network Media
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Standards
- 5/8*10/100/1000Mbps RJ45 Ports, Auto Negotiation,
Auto MDI/MDIX
- 10BASE-T: UTP Cat 3, 4, 5 cable (maximum 100m)
- 100BASE-TX/1000BASE-T: UTP Cat 5, 5e or above
cable (maximum 100m)
- 9V DC/0.5A
Power Supply
- IGMP Snooping, Giga-Lite
Advanced
Features
Transfer Method
- Store-and-Forward
LED Indicators
- 1*Power, 5/8*LAN
Dimensions
(L x W x H)
- 5.2 x 3.0 x 0.9 in. (132 x 75 x 24mm)
Connect S808G’s LAN port to Router’s LAN port by cable.
Connect PC’s RJ45 port to S808G’s any LAN port by
cable.
Plug S808G’s power adapter into outlet.
3
Router
S808G
PC
For more information, please go to www.totolink.net
Information in this document is subject to change without prior notice.
Copyright ⓒ TOTOLINK., All rights reserved.
台灣用戶請參閱背面繁體中文說明 Note: For simplicity, we will take S808G for example throughout this Guide.
P/N:134013020_Ver201709
单色/80G书纸 210*285mm
   
 
: S505G & S808G
  
 
1* 5/8-  10/100/1000/
1*  
1*    
S808G
LED-
LAN
PWR


.
.
.
.

    

    , 
   
 
 
 




- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x

- 5/8*10/100/1000/ RJ45 , Auto Negotiation,
Auto MDI/MDIX
- 10BASE-T:   UTP Cat 3, 4, 5 (. 100)
- 100BASE-TX/1000BASE-T:   UTP Cat 5,
5e   (. 100)
- 9 DC/0.5A

- IGMP Snooping, Giga-Lite


 
-   
LED-
- 1*Power, 5/8*LAN

( x x )
- 132 x 75 x 24 
 LAN- S808G  LAN-   
 Ethernet-.
  RJ45     LAN-
S808G   Ethernet-.
   S808G  .
3

S808G
    www.totolink.net
         .
Copyright ⓒ TOTOLINK., All rights reserved.
台灣用戶請參閱背面繁體中文說明
.:       
 S808G.
P/N:134013020_Ver201709
单色/80G书纸 210*285mm




