Operation
Dry Operation
Remote controller
1. Unit start
Link with electronic power.
Press ON/OFF on the remote controller, unit starts.
The liquid crystal will display the working state of last
time (Except Timer, Sleep, Power/Soft and Health
airflow).
2.Select operation mode
Press FAN button. For each press, fan speed changes as
follows:
Press MODE button. For each press, operation mode
changes as follows:
Remote controller:
Remote controller:
Then Select DRY operation
Press TEMP. button
Every time the button is pressed, temp.setting
increase 1 C,if kept depressed, it will increase
rapidly
Every time the button is pressed, temp.setting
increase 1 C,if kept depressed, it will decrease
rapidly
Select a desired temperature.
4.Fan speed selection
3.Select temp.setting
5.Unit stop
Air conditioner is running under displayed wind speed
In DRY mode, when room temperature becomes 2
O
C
higher than temp.setting,unit will run at setting temp..
Press ON/OFF button, the unit stops.
COOL operation starts when room
temp.is higher than temp.setting.
On reaching temp.setting +2
o
C
unit will run in mild DRY mode.
Ultra-low air flow
Temp.setting+2
o
C
Temp.setting
LOW
MED
HI
AUTO
COOL DRY FAN HEAT
11
On the displaying board,colorful displaying bar will
display water-like color.
When FAN is set to AUTO, the air conditioner
automatically adjusts the fan speed according to room
temperature.
AUTO
