Haier HSU-12CVY03 [12/25] Operation
![Haier HSU-12CVY03 [12/25] Operation](/views2/1825731/page12/bgc.png)
FRESH
STERILIZE
Dry Operation
Remote controller
Operation
2.Select operation mode
Press FAN button. For each press, fan speed changes as
follows:
Press MODE button. For each press, operation mode
changes as follows:
Remote controller:
Remote controller:
Then Select DRY operation
Press TEMP. button
Every time the button is pressed, temp.setting
increase 1 C,if kept depressed, it will increase
rapidly
Every time the button is pressed, temp.setting
decrease 1 C,if kept depressed, it will decrease
rapidly
Select a desired temperature.
4.Fan speed selection
3.Select temp.setting
5.Unit stop
Press ON/OFF button, the unit stops.
LOW
MED
HI
AUTO
1. Unit start
Press ON/OFF on the remote controller, unit starts.
COOL operation starts when room
temp.is higher than temp.setting.
On reaching temp.setting +2 C
unit will run in mild DRY mode.
Ultra-low air flow
Temp.setting+2 C
Temp.setting
11
SWING FAN
TEMP
MODE
HEALTH AIRFLOW
SLEEP
HEALTH
CLOCK SET
TIMER
RESET CODE
LIGHT LOCK
o
C
AM
ON
OFF
4
Air conditioner is running under displayed fan speed.
In DRY mode, when room temperature becomes
lower than temp.setting+2
o
C,unit will run intermittently
at LOW speed regardless of FAN setting.
AUTO COOL DRY FAN
