Haier HW-18CV03 [5/15] Operation guide
![Haier HW-18CV03 [5/15] Operation guide](/views2/1825915/page5/bg5.png)
Operation Guide
Operation panel
Mode selection
LOW
COOL
HIGH
COOL
HIGH
FAN
LOW
FAN
OFF
OFF ON
Auto swing
Temp. setting
MIN
COOL
MAX
COOL
1
2
3
4
5
6
7
8
9
10
Auto swing switch
Mode selection switchThermostat switch
2
WAIT THREE MINUTES BEFORE RESTARTING
