Maintenance
Air filter cleaning: Please clean the air filter every two weeks
When dirt accumulates in the air filter, air circulation will be blocked, and causes
poor
Removal of air filter
(1) Loosen the air inlet by pushing " PUSH " at
both edges as shown.
(2) Open the air inlet.
(3) Hold the handle at lower part of the air filter
and draw outward to remove the air filter.
1. Gently tap the dirt off the air filter.
2. Carefully wash the air filter in warm water
(below 40
o
C). To obtain better cleaning
effect, soapy water or neutral detergent
may be used.
3. Flush the air filter carefully with clean water
after removing the dirt. Let it dry
completely.
(1) Put the air filter on.
(2) Push the part marked " PUSH " until you hear a click.
Air filter cleaning
Installation of filter
Washing
air filter
PUSH
Air inlet
PUSH
(1) Loose the air filter by pushing " PUSH "
at both ends of air inlet.
(2) Hold the air filter by frame and lift it
forward for approx. 5 mm.
(3) Pull it out downward .
(1) Hold the filter by its frame and push it upward along
the
groove under air inlet until it comes to a complete stop.
(2) Push the part marked with " PUSH " until you hear a
click.
For HW-18L03(T3):
For HW-24CE03:
For HW-18L03(T3):
For HW-24CE03:
WAIT 3 MINUTES BEFORE RESTARTING
VENTILATOR
Mode selection
Temp. setting
Auto swing
PUSH
PUSH
WAIT 3 MINUTES BEFORE RESTARTING
VENTILATOR
Mode selection
Temp. setting
Auto swing
Air Conditioner
Edition:2006/01/19
