Haier HW100-B14959S8U1 [10/36] Control panel
![Haier HW100-B14959S8U1 [10/36] Control panel](/views2/1826875/page10/bga.png)
3-Control panel
EN
10
3.4.4 Function button “Speed“
Touch this button (Fig. 3-9) to change or deselect the spin of
the programme. If no value is illuminated the display" "the
laundry will not spin.
0
3.4.7 Function button “Start/Pause“
Touch this button (Fig. 3-12) gently to start or interrupt the
currently displayed programme.
3.4.5 Function button “Extra Rinse”
Touch this button (Fig. 3-10) to rinse the laundry more
intense
with fresh water. This is recommended for people
with sensitive
skin.
By touching the button several times z ero to three additional
cycles can be selected. They appear in the display
with P--0/
P--1/P--2/P--3.Different programme optiones are diffrent.
3.4.2 Function button “ Steam“
Touch this button (Fig. 3-7) the steam program can be selected.
When this program is selected, the default temperature is the
max temperature of this program.You can select if you require
this function when programs"Smart,Mix,Synthetic, Cotton,Alle-
rgy Care “ are used. When you select the program "steam " the
icon light up to warn you ,the icon turns off when the program is
canceled .
When you select the program , you cannot change the temper-
ature . If you press the temperature button the program will be
canceled .Switch on the washing machine and select this program
If the washing machine is working you can not select this program .
Steam
Extra Rinse
Speed
3-9
3-10
3-11
3-7
3-8
3-12
Temp.
Temp.
3.4.3 Function button “Temp.“
Touch this button (Fig. 3-8) to change the washing temperature
of the programme. If no value is illuminated(the display" ") the
water will not heated.
--
I-time
3.4.6 Function button ””
Not all programmes can select this function. See P12 for pro-
grams that can select this function.
different washing time.
11
Note: Liquid detergent
If using liquid detergent, it is not recommended to activate the end time delay.
