Haier HW80-1401B-U [18/20] Maintenance
![Haier HW80-1401B-U [18/20] Maintenance](/views2/1827340/page18/bg12.png)
18
maintenance
DisplAy coDes
DISPLAy CODES AND SPECIAL fUNCTIONS
¬ Control panel lock function: Press the "Delay" and the "Start/Pause" buttons simultaneously for 3 seconds after starting a program.
It can no longer be changed by operating buttons or knobs. To unlock press the "Delay" and "Start/Pause" buttons again for 3
seconds.
¬ Power-off memory function: In case of abrupt power failure or the need to cut off the power during a program cycle, the present
settings will be saved and the preset operation will resume when the power is on again.
¬ To cancel a program
Press the "Start/Pause" button, then switch off the power and the program is automatically cancelled. Turn the program selector
again to choose another program.
Alarm sound can be cancelled if it is needed.Please follow the instruction as below:
Switch on the washing machine and turn the program knob to spin cycle, then press the "Delay" and "Extra rinse" button, hold on for
3 seconds.The "bEEP OFF" will be displayed on the screen which indicates that alarm sound has been canceled. To operate the above
steps again so the alarm sound can be recovered and the display will show "bEEP ON".
CODES
CAUSES SOLUTIONS
Err1 ¬ Door is not properly shut. _ Shut the door properly.
Err2 ¬ Drainage error, water not emptied within 6
minutes.
_ Clean the filter and check the drain hose for blockage. If error
still exists, please contact the maintenance personnel.
Err3 ¬ Temperature sensor not properly connected or
damaged.
_ Contact the maintenance personnel.
Err4
¬ Heater error (Appears at the end of a cycle).
_ Reduce load and then start washing again. If problem still
exists, please contact the maintenance personnel.
Err5 ¬Water level not met in 8 minutes.
¬The height of the drain hose is below 80 cm.
¬ The drain hose is in water.
_ Make sure that tap is turned on, and water pressure is normal.
If problem still exists, please contact the maintenance personnel.
_ Install drain hose within 80-100 cm of height.
_ Make sure the drain hose is not in water.
Err6 ¬ Motor error. _ Contact the maintenance personnel.
Err7 ¬ Motor error. _ Contact the maintenance personnel.
Err8 ¬ Water exceeds protective level. _ Contact the maintenance personnel.
End ¬ End of wash cycle.
1:25 ¬The remaining time is 1 hour 25 minutes.
19:25 ¬Status information:Preset time for delayed operation.
UNb After the last rinsing cycle finishes,spinning fails completely due to unbalance of the laundry.
