Haier HA800TE [7/18] Installation

Connection of water inlet hose and washing machine

Waterdrainagehose

Connection of power supply

The height of the terminal of the water drainage

hose should be between 80cm-100cm, the water

drainage hose must be securely placed on the clip

on the back of the washing machine.

Use the water drainage support supplied as an

accessory for proper installation of the water drain-

age hose .fix the water drainage hose support with

waterproof sring.Do not use an excessively long wa-

ter drainage hose and contract the authorized tech-

nician if the water drainage hose needs to be

extended.the water drainage hose should not be ex-

tended more than250cm.(longer extension will result

in concurrent water inflow and outflow).The diam-

eter of the extension hose should be the same as

the original hose.

caution:water drainage hose must not be immersed

in water.the original and extension hoses should be

tightly connected .

Installation

Check the following items before connection to the power supply.

The socket conforms to the maximun power load(The maximum current load of the socket and

power supply cable should not be less than 15A).

Power supply voltage conforms to the required value.

The power supply socket and the plug of the washing machine compatible,if they are compat-

ible ,Refer to a washing machine technician or a Haier designated service point for power cable

replacement.The washing machine should be connected to an earth before use.

Supplementary earth cable should not be necessary if the socket is connected to the earth.

Supplementary earth cable should be installed on the upper back of the washing machine

andconnected to an earth if the power supply socket has no earth connection.

100cm

80cm
