Specifications

General DXR15 DXR12 DXR10 DXR8 DXS15 DXS12

System Type 2-way, Bi-amp Powered Speaker, Bass-reflex Type Powered Subwoofer, Band-pass Type

Frequency Range (-10dB) 49Hz – 20kHz 52Hz – 20kHz 56Hz – 20kHz 57Hz – 20kHz 45Hz – 160Hz 47Hz – 160Hz

Coverage Angle H90° x V60° Constant Directivity Horn –

Crossover Type FIR-X tuning

™ (Linear Phase FIR Filter) –

Crossover Frequency 2.1kHz 2.1kHz 2.3kHz 2.4kHz –

Measured Maximum SPL (peak)

IEC noise@1m

133dB SPL 132dB SPL 131dB SPL 129dB SPL 132dB SPL 131dB SPL

Transducer DXR15 DXR12 DXR10 DXR8 DXS15 DXS12

LF Diameter 15" Cone 12" Cone 10" Cone 8" Cone 15" Cone 12" Cone

Voice coil 2.5" 2.5" 2" 2" 2.5" 2.5"

Magnet Ferrite

HF Diaphragm 1.4" –

Type 1" Throat Compression Driver –

Magnet Ferrite –

Enclosure DXR15 DXR12 DXR10 DXR8 DXS15 DXS12

Material, Finish, Color ABS, Matte Black Wood, Paint, Black

Floor Monitor Angle 50° Symmetrical 50° Symmetrical 50° – –

Dimensions

(WxHxD, with rubber feet)

445×700×380 mm

(17-1/2" x 27-1/2"

x 15")

362×601×350 mm

(14-1/4" x 23-5/8"

x 13-3/4")

305×502×310 mm

(12" x 19-3/4"

x 12-1/4")

280×458×280 mm

(11" x 18" x 11")

478×618×624 mm

(18-7/8" x 24-3/8"

x 24-1/2")

397×563×594 mm

(15-5/8" x 22-1/8"

x 23-3/8")

Net Weight 22.5kg (49.6lbs) 19.3kg (42.5lbs) 14.6kg (32.2lbs) 13.5kg (29.8lbs) 38.0kg (83.8lbs) 33.0kg (72.8lbs)

Handles Aluminium die-cast (Side x 2) Aluminium die-cast (Top x 1) Metal (Side x 2)

Pole Socket 35mm with 2-way feature (0 or 7 degree) 35mm (Top)

Rigging points Top x 2, Rear x 1

(Fits for M10 x 18mm eyebolts)

Top x 2, Rear x 1

(Fits for M8 x 15mm eyebolts)

–

Optional Accessory (U-bracket) UB-DXR15 UB-DXR12 UB-DXR10 UB-DXR8 –

Amplifier DXR15 DXR12 DXR10 DXR8 DXS15 DXS12

Amplifier Type Class-D Class-D

Power Rating

Dynamic 1100W (LF: 950W, HF: 150W) 950W

Continuous 700W (LF: 600W, HF: 100W) 600W

Cooling Fan cooling, 4 speeds

AD/DA 24bit 48kHz sampling

Signal Processing 48bit (Accumulator: 76bit)

HPF/LPF OFF, 100, 120Hz 24dB/oct HPF 80, 100, 120Hz 24dB/oct LPF

DSP preset D-CONTOUR: FOH/MAIN, MONITOR, OFF D-XSUB: BOOST, XTENDED-LF, OFF

Protection Speaker Clip limiting, Integral Power Protection, DC-fault

Amplifier Thermal, Output over current

Power supply Thermal, Output over voltage, Output over current

Connectors Input INPUT1: XLR3-31 x 1, INPUT2: Phone x 2 (Unbalanced),

INPUT3: RCA PIN x 2 (Unbalanced)

INPUT: XLR3-31 x 2

Output THRU: XLR3-32 x 1 (Parallel with INPUT1), LINK OUT: XLR x1 THRU: XLR3-32 x 2 (Parallel with INPUT)

Input

Impedance

INPUT1 LINE: 12kΩ, MIC: 8kΩ 10kΩ

INPUT2, 3 L, R: 40kΩ, MONO: 20kΩ –

Input Sensitivity

(LEVEL:

Maximum)

INPUT1 LINE: +1dBu, MIC: -32dBu +1dBu

INPUT2, 3 -13dBu –
