8 INSTRUCTION MANUAL

DEVICE DESCRIPTION

Beaters

Dough hooks

Eject button attachments

Nozzles otation speed regulator

(5 modes)

Housing

OPERATION OF THE DEVICE

Using dough hooks/beaters

 Set the switch (4) to "0" and make sure that the mixer is disconnected from the mains.

 Insert the dough hooks or beaters (1 or 2) into the holes provided for them on the mixer until

they are fixed. Easy turning will make it easier to fix the attachments.

 Never use different nozzles at the same time!

 Insert the plug into a grounded outlet with a mains voltage of 220-240 V ~ 50 Hz.

 Using the speed switch (4) on the mixer, you can set 5 rotation speeds.

 To remove the dough hooks/beaters (1 or 2), set the switch (4) to "0" - off and make sure that

the mixer is disconnected from the mains.

 Press the attachment lock button (3) to pull the attachment rod out of the hole. In the same

way, remove the other pair nozzle.

The use of the device

 Insert the dough hooks/beaters (1 or 2) as described in the section "Using dough

hooks/beaters".

 Fill the dishes with the necessary ingredients.

 Insert the plug into a grounded outlet with a mains voltage of 220-240 V ~ 50 Hz.

 Using the speed switch (4) on the mixer, you can set different rotation speeds (1-5).

 To stop the device, set the switch (4) to "0" and disconnect the mixer from the mains.

 Remove the dough hooks /beaters (1 or 2) as described in the section "How to use dough

hooks/beaters".

 After use, wash the nozzles and wipe them thoroughly with a dry towel.

CLEANING AND CARE

 Disconnect the appliance from the power supply before cleaning.

 Disconnect the attachments.

 Wash the nozzles in warm soapy water, rinse and dry thoroughly.

 Clean the appliance before putting it away for long-term storage.

 Do not wrap the power cord around the appliance.

 Keep the appliance in a cool, dry place out of the reach of children.

 Appliances stored in a closed dry place at an ambient temperature not higher than + 40 ° C with

relative humidity above 70% and the absence in the environment of dust, acid and other fumes

adversely affecting materials appliances.
