14 Service manual
Indoor noise level (Hi/Mi/Lo) dB(A) 44/40/35 48/44/38 48/45/39
Indoor unit Dimension(W*D*H) mm 905x275x198 1030x315x218 1030x315x218
Packing (W*D*H) mm 970x270x345 1115x395x300 1115x395x300
Net/Gross weight Kg 9.8/11.7 12 / 15 12 / 15
Outdoor fan
motor
Model YDK24-6(B) YDK48-6H(A) YDK100-6D(B)
Brand Welling Welling Welling
Input W 77.3 110 177
Capacitor uF 2.5 3.0 5.0
Speed r/min 860 / -- / -- 890 / -- / -- 875 / -- / --
Outdoor coil a.Number of rows 1.6 2 2
b.Tube pitch(a)x row
pitch(b)
mm 21x13.37 21x13.37 21x13.37
c.Fin spacing
mm 1.5 1.4 1.4
d.Fin type (code) Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
e.Tube outside dia.and type
mm Φ7,innergroove tube Φ7,innergroove tube Φ7,innergroove tube
f.Coil length x height x
width
mm
（769+474）x504x13.37
653x546x26.74 760*546*26.74
g.Number of circuits 4 4 4
Outdoor air flow m3/h 2000 2400 2500
Outdoor noise level dB(A) 58 60 62
Outdoor unit Dimension(W*D*H) mm 780x250x540 760x285x590 820x330x595
Packing (W*D*H) mm 910x335x585 887x355x645 940x415x645
Net/Gross weight Kg 32.1/34.2 37.5 / 40 43.5 / 46.5
Refrigerant type g R410A/1130g R410A/1400g R410A/1600g
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side mm(inch
)
Φ6.35/Φ12.7(1/4"/1/2") Φ9.52/Φ16(3/8"/5/8") Φ9.52/Φ16(3/8"/5/8")
Max. refrigerant pipe
length
m 20 25 25
Max. difference in level
m 8 10 10
Connection wiring 2.5(Optional) 1.0(Optional) 1.0(Optional)
Plug type 14# 2.5 2.5
Thermostat type Remote Control Remote Control Remote Control
Operation temp
℃
17-30 17-30 17-30
Ambient temp (cooling/heating)
℃
18-43/-7-24 18-43/-7-24 18-43/-7-24
Application area m2 23-39 29-48 32-53
