Beon BN-228 [6/12] Instruction manual

6 INSTRUCTION MANUAL

DESCRIPTION

1. Bowl rotation lever

2. Stainless steel bowl

3. Nozzle

4. Rims removing button

5. Speed adjustment

6. Motor block

7. Air Vent

8. Button to lock/unlock the transmission

shaft

9. Nonskid legs on suckers

10. Base mixer

11. Rotating platform

DEVICE OPERATION

1. Install the mixer bowl: hold the rotating platform (11) with one hand

and scroll the mixer bowl (2) on it to the hour hand until it clicks the

other hand.

2. Place the required attachments on the mixer and secure them in the correct position.

3. Connect the device to the network.

4. Add ingredients.

5. Select the desired speed. The mixer will begin mixing the ingredients in the bowl.

6. When you are done, stop the mixer by adjusting the speed selector lever (5) to «0».

7. Wait until the beaters/hooks stop rotating, press the nozzle extraction button (4) to remove the

beaters/hooks.

ATTENTION! Turn off the instrument before replacing accessories or approaching use.

8. Turn off the instrument when you are done. Clean the beaters / hooks for the dough with water.

Wipe dry, store in the box along with the main body.

ATTENTION!

Do not run the mixer continuously longer than 5 minutes. Switch off and let it rest for at least 1

minute to cool down the motor.

CLEANING AND CARE

1 Before cleaning the equipment, please adjust the speed selection button to the “0” position.

Unplug the power cord.

2. Press the transfer shaft unlock button, lift the engine back and remove the bowl from the

equipment, holding the rotating platform (11) and at the same time turning the bowl

counterclockwise.

3. Remove the beaters or dough hook using the beaters extraction button (4).
