Beon BN-2803 [11/16] Instruction manual

11 INSTRUCTION MANUAL

 When working with viscous or sufficiently solid products, it is recommended to use the juicer

mode at high speed "II" to avoid stopping the rotation of the filter grater (4).

 The juicer will only turn on if all the removable parts are installed correctly and the lid (3) is

secured with a retainer (8).

 Only load products into the loading neck (2) of the lid (3) while the filter grater (4) is rotating.

 Gradually lower the pre-cut vegetables or fruits into the loading neck (2) of the lid (3) and press

them lightly with the pusher (1). Do not push the pusher (1) too hard, as this may reduce the

amount of juice received and even stop the rotation of the grater filter (4). The slower the

processing of vegetables or fruits, the greater the juice output.

 Do not put your fingers or any other objects in the loading neck (2) of the lid (3).

 Check the filter grater (4) periodically during operation for any clogging of the mesh with pulp,

if necessary, flush the filter grater (4), turn off the juicer and remove the plug from the power

outlet before removing the filter grater.

 Make sure that the spin-off container (11) is filled if the container (11) is full, turn off the juicer,

remove the plug from the power outlet, and remove the spin-offs.

 ATTENTION! The maximum allowed time of continuous operation of the juicer is no more than

5 minutes, followed by a break of at least 3 minutes.

 After processing 500 g of solid and fibrous products (citrus, pineapples, apples, carrots, etc.),

disassemble and clean the device. Failure to comply with this requirement may cause the grater

mesh to jam and make cleaning the device more difficult.

 After using the juicer, turn it off by setting the switch (9) to the "0" position and remove the

plug from the power outlet.

OVERHEATING PROTECTION

 The overheat protection system shuts off the electric motor when the temperature is

exceeded.

 If the juicer turns off during use, set the operating mode switch (10) to "0" and remove the

mains plug from the electrical outlet.

 Allow the device to cool down for 30-40 minutes, then turn it on again. During the juicer

operation, observe the time cycles (5 minutes –work, 20 minutes – break), do not press with

great force on the pusher (1), do not block the air holes on the bottom of the juicer body.

CLEANING AND MAINTENANCE

 Always turn off the device and disconnect it from the power supply after you finish working or

before cleaning.

 Disassemble and clean the juicer after each use, following the recommendations listed below.

 Remove the pusher (1) from the loading neck (2) of the cover (3).

 Lower the lock (8) and remove the cover (3).

 To facilitate the removal of the filter grater (4), remove it together with the juice collector (5),

holding the juice collector (5) and lifting it up.

 It is recommended to wash all removable parts with warm water and neutral detergent

immediately after use.

 It is more convenient to wash the holes of the grater filter (4) from the outside using a suitable

brush.

 Be careful when washing the filter grater (4), the surface of the disc grater is very sharp.
