11 INSTRUCTION MANUAL

 Connect the appliance to the mains, set the temperature regulator (2) and

 the steam regulator (7) to the maximum position.

 The burning heat indicator lamp (10) indicates that the iron is heating up.

 When the heat indicator (10) goes out – the iron will reach the desired temperature.

 The steaming function can only be performed at maximum heating temperatures. Otherwise,

hot water may be released.

 Set the steam regulator to the minimum "0"position.

 When the heat indicator turns off, it means that the iron has warmed up, has reached the

selected temperature and is ready for dry Ironing.

 You can iron in dry mode even if the tank is filled with water. However, in case of continuous

operation in this mode it is not recommended to pour too much water into the tank.

 Attention! If during operation you need to use steam and there is no water in the tank,

disconnect the iron from the mains and wait until it cools down, and only then fill in the water.

 If you need to wet the cloth, press the water spray button (8). Water sprayed through the

spraying device, evenly moistens the product.

 At the end of Ironing, allow the sole of the iron to cool to room temperature and disconnect the

 In any Ironing mode, press the water spray button to moisten the cloth (8).

 Sometimes it is necessary to press the button several times, while in the tank should be water.

Burst of steam

 This function provides an extra amount of steam to remove stubborn wrinkles.

 Set the steam regulator (7) to "0", then fill the water tank with distilled or boiled water (not

more than 350 ml).

 Plug the iron into an outlet, set the temperature regulator and the steam regulator (7) to the

maximum position.

 Luminous heat indicator (10) informs about the heating of the iron. When the indicator (10)

goes out, it means that the set temperature is reached.
