Oasis Inverter DM12-01.01.10en
12 Service manual
4. Dimension
4.1 Indoor Unit
Model W D H
MS11MU-09HRDN1
750 198 280
MS11MU-12HRDN1
835 198 280
MS11MU-18HRDN1
990 218 315
MS11MU-24HRDN1
1186 258 340
