2
12.5. ON Timer Control ----------------------------------------35
12.6. OFF Timer Control---------------------------------------36
12.7. Auto Restart Control------------------------------------- 36
12.8. Indication Panel------------------------------------------- 36
12.9. Patrol Operation ------------------------------------------36
12.10. e-ion Operation ------------------------------------------- 38
13 Protection Control---------------------------------------------- 41
13.1. Protection Control For All Operations---------------41
13.2. Protection Control For Cooling & Soft Dry
Operation---------------------------------------------------42
13.3. Protection Control For Heating Operation ---------43
14 Servicing Mode --------------------------------------------------45
14.1. Auto OFF/ON Button------------------------------------45
14.2. Select Remote Control Transmission Code ------- 45
14.3. Remote Control Button ---------------------------------46
15 Troubleshooting Guide----------------------------------------47
15.1. Refrigeration Cycle System--------------------------- 47
15.2. Relationship Between The Condition Of The
Air Conditioner And Pressure And Electric
Current ----------------------------------------------------- 48
15.3. Breakdown Self Diagnosis Function---------------- 49
15.4. Error Codes Table --------------------------------------- 50
16 Disassembly and Assembly Instructions -------------- 51
16.1. Indoor Electronic Controllers, Cross Flow Fan
And Indoor Fan Motor Removal Procedures ----- 51
17 Technical Data--------------------------------------------------- 55
17.1. Operation Characteristics ----------------------------- 55
17.2. Sensible Capacity Chart ------------------------------- 71
18 Exploded View and Replacement Parts List----------- 72
18.1. CS-E24GKES CS-E28GKE -------------------------- 72
18.2. CU-E24GKE CU-E28GKE---------------------------- 74
1 Safety Precautions
• Read the following “SAFETY PRECAUTIONS” carefully before perform any servicing.
• Electrical work must be installed or serviced by a licensed electrician. Be sure to use the correct rating of the power plug and
main circuit for the model installed.
• The caution items stated here must be followed because these important contents are related to safety. The meaning of each
indication used is as below.
Incorrect installation or servicing due to ignoring of the instruction will cause harm or damage, and the seriousness is classified
by the following indications.
The items to be followed are classified by the symbols:
• Carry out test running to confirm that no abnormality occurs after the servicing. Then, explain to user the operation, care and
maintenance as stated in instructions. Please remind the customer to keep the operating instructions for future reference.
This indication shows the possibility of causing death or serious injury.
This indication shows the possibility of causing injury or damage to properties.
This symbol denotes item that is PROHIBITED from doing.
1. Engage dealer or specialist for installation and servicing. If installation or servicing done by the user is defective, it will cause water leakage,
electrical shock or fire.
2. Install according to this installation instructions strictly. If installation is defective, it will cause water leakage, electrical shock or fire.
3. Use the attached accessories parts and specified parts for installation and servicing. Otherwise, it will cause the set to fall, water leakage,
fire or electrical shock.
4. Install at a strong and firm location which is able to withstand the set's weight. If the strength is not enough or installation is not properly
done, the set will drop and cause injury.
5. For electrical work, follow the local national wiring standard, regulation and the installation instruction. An independent circuit and single
outlet must be used. If electrical circuit capacity is not enough or defect found in electrical work, it will cause electrical shock or fire.
6. Use the specified cable and connect tightly for indoor/outdoor connection. Connect tightly and clamp the cable so that no external force will
be acted on the terminal. If connection or fixing is not perfect, it will cause heat-up or fire at the connection.
7. Wire routing must be properly arranged so that control board cover is fixed properly. If control board cover is not fixed perfectly, it will cause
heat-up at connection point of terminal, fire or electrical shock.
