Panasonic CS-E15DKEW [2/136] Contents
![Panasonic CS-E15DKEW [2/136] Contents](/views2/1832456/page2/bg2.png)
1 Safety Precautions 3
2 Features
5
2.1. Wall Type
6
2.2. Duct Type
9
2.3. Ceiling Floor Type
12
2.4. Mini-Cassette Type
14
3 Product Specifications
16
3.1. Wall Type
16
3.2. Duct Type
17
3.3. Ceiling Floor Type
18
3.4. Mini-Cassette Type
19
3.5. Outdoor unit: CU-3E18EBE
20
4 Dimensions
21
4.1. Wall Type
21
4.2. Duct Type
23
4.3. Ceiling Floor Type
25
4.4. Mini-Cassette Type
26
4.5. Outdoor Unit
27
5 Refrigeration Cycle Diagram
28
6 Wiring Diagram
29
6.1. Wall Type
29
6.2. Duct Type
30
6.3. Ceiling Floor Type
31
6.4. Mini-Cassette Type
32
6.5. Outdoor Unit
33
7 Electronic Circuit Diagram
34
8 Operation Details
36
8.1. Wall Type
36
8.2. Duct Type
53
8.3. Ceiling Floor Type
59
8.4. Mini-Cassette Type
73
8.5. Outdoor Unit Operation
87
8.6. Forced Cooling Operation Control
88
8.7. Wiring Error Check Control
89
8.8. Outdoor Unit - Check Point
90
9 Self Diagnosis Display
91
9.1. Breakdown Self Diagnosis Function (Three Digits
Alphanumeric Code)
91
9.2. Error Code
92
10 Installation Information
96
11 Installation Instructions
97
12 Disassembly of Parts
108
12.1. Wall Type
108
12.2. Duct Type
110
12.3. Ceiling Floor Type
112
12.4. Mini-Cassette Type
113
12.5. Outdoor Unit
115
13 Technical Data
117
13.1. Operation Characteristics
117
14 Exploded View and Replacement Parts List
119
14.1. Wall Type
119
14.2. Duct Type
125
14.3. Ceiling Floor Type
127
14.4. Mini-Cassette Type
129
14.5. Outdoor Unit
134
CONTENTS
Page Page
2
Содержание
- Contents 2
- Page page 2
- Carry out test running to confirm that no abnormality occurs after the servicing then explain to user the operation care and maintenance as stated in instructions please remind the customer to keep the operating instructions for future reference 3
- Electrical work must be installed or serviced by a licensed electrician be sure to use the correct rating of the power plug and main circuit for the model installed 3
- Incorrect installation or servicing due to ignoring of the instruction will cause harm or damage and the seriousness is classified by the following indications 3
- Read the following safety precautions carefully before perform any servicing 3
- Safety precautions 3
- The caution items stated here must be followed because these important contents are related to safety the meaning of each indication used is as below 3
- The items to be followed are classified by the symbols 3
- Features 5
- Product specifications 16
- Specifications are subject to change without notice for further improvement 16
- Wall type 16
- Duct type 17
- Specifications are subject to change without notice for further improvement 17
- Ceiling floor type 18
- Specifications are subject to change without notice for further improvement 18
- Mini cassette type 19
- Specifications are subject to change without notice for further improvement 19
- Outdoor unit cu 3e18ebe 20
- Dimensions 21
- Wiring diagram 29
- Basic function 36
- Internal setting temperature 36
- Inverter control which equipped with a microcomputer in determining the most suitable operating mode as time passes automatically adjusts output power for maximum comfort always in order to achieve the suitable operating mode the microcomputer maintains the set temperature by measuring the temperature of the environment and performing temperature shifting the compressor at outdoor unit is operating following the frequency instructed by the microcomputer at indoor unit that judging the condition according to internal setting temperature and intake air temperature 36
- Once the operation starts remote control setting temperature will be taken as base value for temperature shifting processes these shifting processes are depending on the air conditioner settings and the operation environment the final shifted value will be used as internal setting temperature and it is updated continuously whenever the electrical power is supplied to the unit 36
- Operation details 36
- Table a auto operation mode setting 36
- Table b outdoor air temperature shifting 36
- Table c power mode shifting 36
- Wall type 36
- After deice complete within 600 sec 37
- Comp starting within 600 sec 37
- Comp stop 37
- During deice 37
- During operation it will compare with the target room temperature offset value at specific period then the room temperature will be updated 37
- Heating zone e and above temperature gap is big and great capacity increased 37
- However if the following condition is occurred temperature cannot detect correctly and therefore no updating will be done 37
- I initial value when operation starts or changing the actual operation mode 37
- Ii updating during operation 37
- Room temperature shift value dgeta 37
- Set the offset value at each operation mode however in order to improve the heating startup efficiency the offset value will be changed based on the gap between setting temperature and room temperature 37
- Table d indoor air temperature shifting 37
- Target room temperature shift value dgetadst 37
- The heat exchanger unit s temperature is different based on operation mode it becomes the action operation mode value 37
- To offset the absolute gap between detection temperature with actual room temperature 37
- Update the room temperature offset value dgeta 37
- When compressor on off correction of detected room temperature by shift value during defrost etc 37
- Simultaneous operation control 38
- Cooling operation 39
- Heating operation 39
- Soft dry operation 39
- Thermostat control 39
- Automatic operation 40
- During operation mode judgment indoor fan motor with speed of lo and outdoor fan motor are running for 30 seconds to detect the indoor intake and outdoor air temperature the operation mode is decided based on below chart 40
- The operation mode chart for this example is as shown in below figure and the operation mode to be performed will depend on indoor intake air temperature and outdoor air temperature at the time when the judgment is made 40
- There is a temperature shifting on t1 t2 and t3 if the operation mode judged is changed from cooling soft dry to heating or vice verse 40
- This mode can be set using remote control and the operation is decided by remote control setting temperature indoor intake air temperature and outdoor air temperature 40
- Values of t1 t2 and t3 depend on remote control setting temperature as shown in below table after the adjustment of t1 t2 and t3 values the operation mode for that particular environment and remote control setting is judged and performed based on the above operation mode chart every 3 hours 40
- A basic rotation speed rpm 41
- Cooling soft dry fan 41
- Heating 41
- Indoor fan motor operation 41
- Refer to the cs e12dkew column for cs e12dkdw 41
- Refer to the cs e15dkew column for cs e15dkdw 41
- Refer to the cs e18dkew column for cs e18dkdw 41
- Refer to the cs e9dkew column for cs e9dkdw 41
- Refer to the cs me7dkeg column for cs me7dkdg 41
- Required rotation speed for fan is set to respond to the remote control setting 10 rpm unit 41
- Cooling 43
- Heating 43
- Ii auto fan speed 43
- Refer to the cs e12dkew column for cs e12dkdw 43
- Refer to the cs e15dkew column for cs e15dkdw 43
- Refer to the cs e18dkew column for cs e18dkdw 43
- Refer to the cs e9dkew column for cs e9dkdw 43
- Refer to the cs me7dkeg column for cs me7dkdg 43
- Airflow direction 45
- Automatic vertical airflow direction can be set using remote control the vane swings up and down within the angles as stated above for heating mode operation the angle of the vane depends on the indoor heat exchanger temperature as figure 1 below when the air conditioner is stopped using remote control the vane will shift to close position 45
- Control at cooling soft dry operation and auto fan speed 45
- Control of airflow direction can be automatic angles of direction is determined by operation mode heat exchanger temperature and intake air temperature and manual angles of direction can be adjusted using remote control 45
- D deodorizing control 45
- I control condition 45
- Ii operation 45
- Manual vertical airflow direction can be set using remote control the angles of the vane are as stated above and the positions of the vane are as figure 2 below when the air conditioner is stopped using remote control the vane will shift to close position 45
- No deodorizing control is performed during on timer standby operation and during freeze prevention control 45
- The odor status is arranged as below and it is shifted as follows 45
- There are two types of airflow vertical airflow directed by horizontal vane and horizontal airflow directed by vertical vanes 45
- Vertical airflow 45
- A powerful button is pressed 46
- A purpose 46
- A quiet operation start condition 46
- Automatic horizontal airflow direction can be set using remote control the vane swings left and right within the angles as stated below for heating mode operation the angle of the vane depends on the indoor heat exchanger temperature as figure 1 below 46
- B control condition 46
- B quiet operation stop condition 46
- B stop by off on switch 46
- C timer off activates 46
- D quiet button is pressed again 46
- Horizontal airflow 46
- Manual horizontal airflow direction can be set using remote control the angles of the vane are as stated below and the positions of the vane are as figure 2 above 46
- Quiet led illuminates 46
- Quiet operation cooling mode cooling area of soft dry mode 46
- To provide quiet cooling operation compare to normal operation 46
- When one of the following conditions is satisfied quiet operation stops 46
- When quiet button at remote control is pressed 46
- Quiet operation heating 47
- Off timer control 48
- On timer control 48
- Powerful mode operation 48
- Auto restart control 49
- Indication panel 49
- Auto operation switch 50
- Ionizer operation 50
- A stopped by on off switch 51
- B operation mode ionizer operation 51
- B timer off activates 51
- C ion feedback signal shows error 51
- C timer during ionizer operation 51
- I purpose 51
- Ii two types of problem detection control 51
- Ionising operation start condition 51
- Ionising operation stop condition 51
- Ionizer problem detection control 51
- Power led also illuminates 51
- Refer to case study in next page for details 51
- To inform user of ionizer problems and detection 51
- When air conditioner unit is in on condition heat cool dry fan auto mode and an ion operation button at remote control is pressed ionizer on ion led illuminates 3 4 51
- When ion is displayed on the remote controller ionizer operates 51
- When one of the following conditions is satisfied ion operation stops 51
- Freeze prevention control 52
- Ionizer operation case study 52
- Duct type 53
- Simultaneous operation control 53
- Indoor fan control 54
- Drain pump control 55
- Auto restart control 56
- Auto button 57
- Other indoor unit operation functions 57
- Drain test sw1 58
- High static pressure switch high state switch sw2 58
- Basic function 59
- Ceiling floor type 59
- Internal setting temperature 59
- Inverter control which equipped with a microcomputer in determining the most suitable operating mode as time passes automatically adjusts output power for maximum comfort always in order to achieve the suitable operating mode the microcomputer maintains the set temperature by measuring the temperature of the environment and performing temperature shifting the compressor at outdoor unit is operating following the frequency instructed by the microcomputer at indoor unit that judging the condition according to internal setting temperature and intake air temperature 59
- Once the operation starts remote control setting temperature will be taken as base value for temperature shifting processes these shifting processes are depending on the air conditioner settings and the operation environment the final shifted value will be used as internal setting temperature and it is updated continuously whenever the electrical power is supplied to the unit 59
- Table a auto operation mode setting 59
- Table b outdoor air temperature shifting 59
- Table c power mode shifting 59
- After deice complete within 600 sec 60
- Comp starting within 600 sec 60
- Comp stop 60
- During deice 60
- During operation it will compare with the target room temperature offset value at specific period then the room temperature will be updated 60
- Heating zone e and above temperature gap is big and great capacity increased 60
- However if the following condition is occurred temperature cannot detect correctly and therefore no updating will be done 60
- I initial value when operation starts or changing the actual operation mode 60
- Ii updating during operation 60
- Room temperature shift value dgeta 60
- Set the offset value at each operation mode however in order to improve the heating startup efficiency the offset value will be changed based on the gap between setting temperature and room temperature 60
- Table d indoor air temperature shifting 60
- Table e 60
- Target room temperature shift value dgetadst 60
- The heat exchanger unit s temperature is different based on operation mode it becomes the action operation mode value 60
- To offset the absolute gap between detection temperature with actual room temperature 60
- Update the room temperature offset value dgeta 60
- When compressor on off correction of detected room temperature by shift value during defrost etc 60
- Simultaneous operation control 61
- Cooling operation 62
- Heating operation 62
- Soft dry operation 62
- Thermostat control 62
- Automatic operation 63
- During operation mode judgment indoor fan motor with speed of lo and outdoor fan motor are running for 30 seconds to detect the indoor intake and outdoor air temperature the operation mode is decided based on below chart 63
- The operation mode chart for this example is as shown in below figure and the operation mode to be performed will depend on indoor intake air temperature and outdoor air temperature at the time when the judgment is made 63
- There is a temperature shifting on t1 t2 and t3 if the operation mode judged is changed from cooling dry to heating or vice verse 63
- This mode can be set using remote control and the operation is decided by remote control setting temperature indoor intake air temperature and outdoor air temperature 63
- Values of t1 t2 and t3 depend on remote control setting temperature as shown in below table after the adjustment of t1 t2 and t3 values the operation mode for that particular environment and remote control setting is judged and performed based on the above operation mode chart every 30 minutes 63
- A basic rotation speed rpm 64
- Cooling soft dry fan 64
- Heating 64
- Indoor fan motor operation 64
- Required rotation speed for fan is set to respond to the remote control setting 10 rpm unit 64
- Cooling 66
- Heating 66
- Ii auto fan speed 66
- Airflow direction 68
- Automatic vertical airflow direction can be set using remote control the vane swings up and down within the angles as stated above for heating mode operation the angle of the vane depends on the indoor heat exchanger temperature as figure 1 below when the air conditioner is stopped using remote control the vane will shift to close position 68
- Control of airflow direction can be automatic angles of direction is determined by operation mode heat exchanger temperature and intake air temperature and manual angles of direction can be adjusted using remote control 68
- Manual vertical airflow direction can be set using remote control the angles of the vane are as stated above and the positions of the vane are as figure 2 below when the air conditioner is stopped using remote control the vane will shift to close position 68
- There is one type of airflow vertical airflow directed by horizontal vane 68
- Vertical airflow 68
- Quiet operation cooling mode cooling area of soft dry mode 69
- Quiet operation heating 69
- On timer control 70
- Powerful mode operation 70
- Auto operation switch 71
- Auto restart control 71
- If power led is blinking the possible operations of the unit are hot start during deice operation operation mode judgment or delay on timer sampling 71
- If timer led is blinking there is an abnormality operation occurs 71
- Indication panel 71
- Off timer can be set using remote control the unit with timer set will stop operate at set time 71
- Off timer control 71
- This type of control is not applicable during on off timer setting 71
- When the power supply is cut off during the operation of air conditioner the compressor will re operate within three to four minutes there are 10 patterns between 2 minutes 58 seconds and 3 minutes 52 seconds to be selected randomly after power supply resumes 71
- When the switch is pressed between 0 to 5 seconds auto mode operation starts to function 71
- When the switch is pressed between 11 to 16 seconds and together with the signal from remote control timer decrement button for 5s the unit can be changed to different controlling setting 4 type of transmission codes 71
- When the switch is pressed between 16 to 21 seconds either h14 error detection selection mode or the remote control signal receiving sound can be cancelled or turned on 71
- When the switch is pressed between 5 to 8 seconds the unit is forced to operate in cooling mode 71
- When the switch is pressed between 8 to 11 seconds the unit will enter forced heating mode standby press timer decrement button for 5s for the unit to operate in heating mode 71
- Dew prevention control 72
- Freeze prevention control 72
- Basic function 73
- Internal setting temperature 73
- Inverter control which equipped with a microcomputer in determining the most suitable operating mode as time passes automatically adjusts output power for maximum comfort always in order to achieve the suitable operating mode the microcomputer maintains the set temperature by measuring the temperature of the environment and performing temperature shifting the compressor at outdoor unit is operating following the frequency instructed by the microcomputer at indoor unit that judging the condition according to internal setting temperature and intake air temperature 73
- Mini cassette type 73
- Once the operation starts remote control setting temperature will be taken as base value for temperature shifting processes these shifting processes are depending on the air conditioner settings and the operation environment the final shifted value will be used as internal setting temperature and it is updated continuously whenever the electrical power is supplied to the unit 73
- Table a auto operation mode setting 73
- Table b outdoor air temperature shifting 73
- Table c power mode shifting 73
- After deice complete within 600 sec 74
- Comp starting within 600 sec 74
- Comp stop 74
- During deice 74
- During operation it will compare with the target room temperature offset value at specific period then the room temperature will be updated 74
- Heating zone e and above temperature gap is big and great capacity increased 74
- However if the following condition is occurred temperature cannot detect correctly and therefore no updating will be done 74
- I initial value when operation starts or changing the actual operation mode 74
- Ii updating during operation 74
- Room temperature shift value dgeta 74
- Set the offset value at each operation mode however in order to improve the heating startup efficiency the offset value will be changed based on the gap between setting temperature and room temperature 74
- Table d indoor air temperature shifting 74
- Target room temperature shift value dgetadst 74
- The heat exchanger unit s temperature is different based on operation mode it becomes the action operation mode value 74
- To offset the absolute gap between detection temperature with actual room temperature 74
- Update the room temperature offset value dgeta 74
- When compressor on off correction of detected room temperature by shift value during defrost etc 74
- Simultaneous operation control 75
- Cooling operation 76
- Heating operation 76
- Soft dry operation 76
- Thermostat control 76
- Automatic operation 77
- During operation mode judgment indoor fan motor with speed of lo and outdoor fan motor are running for 30 seconds to detect the indoor intake and outdoor air temperature the operation mode is decided based on below chart 77
- The operation mode chart for this example is as shown in below figure and the operation mode to be performed will depend on indoor intake air temperature and outdoor air temperature at the time when the judgment is made 77
- There is a temperature shifting on t1 t2 and t3 if the operation mode judged is changed from cooling soft dry to heating or vice versa 77
- This mode can be set using remote control and the operation is decided by remote control setting temperature indoor intake air temperature and outdoor air temperature 77
- Values of t1 t2 and t3 depend on remote control setting temperature as shown in below table after the adjustment of t1 t2 and t3 values the operation mode for that particular environment and remote control setting is judged and performed based on the above operation mode chart every 30 minutes 77
- A basic rotation speed rpm 78
- Cooling soft dry fan 78
- Heating 78
- Indoor fan motor operation 78
- Required rotation speed for fan is set to respond to the remote control setting 10 rpm unit 78
- Cooling 80
- Heating 80
- Ii auto fan speed 80
- Airflow direction 82
- Automatic vertical airflow direction can be set using remote control the vane swings up and down within the angles as stated above for heating mode operation the angle of the vane depends on the indoor heat exchanger temperature as figure 1 below when the air conditioner is stopped using remote control the vane will shift to close position 82
- Control at cooling soft dry operation and auto fan speed setting 82
- Control of airflow direction can be automatic angles of direction is determined by operation mode heat exchanger temperature and intake air temperature and manual angles of direction can be adjusted using remote control 82
- D deodorizing control 82
- I control condition 82
- Ii operation 82
- Manual vertical airflow direction can be set using remote control the angles of the vane are as stated above and the positions of the vane are as figure 2 below when the air conditioner is stopped using remote control the vane will shift to close position 82
- No deodorizing control is performed during on timer standby operation and during freeze prevention control 82
- The odor status is arranged as below and it is shifted as follows 82
- There is one type of airflow vertical airflow directed by horizontal vane 82
- Vertical airflow 82
- Quiet operation cooling mode cooling area of soft dry mode 83
- Quiet operation heating 83
- Powerful mode operation 84
- Auto operation switch 85
- Auto restart control 85
- From the above judgment the decided operation will start operate earlier than the set time as shown below 85
- If power led is blinking the possible operations of the unit are hot start during deice operation operation mode judgment or delay on timer sampling 85
- If timer led is blinking there is an abnormality operation occurs 85
- Indication panel 85
- Minutes before the set time indoor at fan speed of lo and outdoor fan motor start operate for 30 seconds to determine the indoor intake air temperature and outdoor air temperature in order to judge the operation starting time 85
- Off timer can be set using remote control the unit with timer set will stop operate at set time 85
- Off timer control 85
- On timer can be set using remote control the unit with timer set will start operate earlier than the setting time this is to provide a comfortable environment when reaching the set on time 85
- On timer control 85
- This type of control is not applicable during on off timer setting 85
- When the power supply is cut off during the operation of air conditioner the compressor will re operate within three to four minutes there are 10 patterns between 2 minutes 58 seconds and 3 minutes 52 seconds to be selected randomly after power supply resumes 85
- When the switch is pressed between 0 to 5 seconds auto mode operation starts to function 85
- When the switch is pressed between 5 to 8 seconds the unit is forced to operate in cooling mode 85
- When the switch is pressed between 8 to 11 seconds the unit will enter forced heating mode standby press timer decrement button for 5s for the unit to operate in heating mode 85
- Dew prevention control 86
- Freeze prevention control 86
- Cooling soft dry and heating operations 87
- During an ongoing operation the difference between the temperature set in each of the rooms and the room temperature is detected the total load is calculated and the compressor frequency is determined on the basis of this information 87
- Immediately after the compressor has started up during an ongoing operation the initial frequency is determined on the basis of the information obtained from the heat exchanger capacities of the indoor units thermostat on and the airflows set by their remote controls 87
- It takes about 180 seconds for the compressor to be restarted after it has stopped re start control 87
- Outdoor unit operation 87
- Room temperature control 87
- When one room turns the thermostat off while two or more indoor units are operating the automatic expansion valve closes to restrict the flow of refrigerant the compressor control is temporarily suspended and both the initial frequency and total load are determined again 87
- When the thermostat is turned off during 1 room operation the outdoor unit s compressor and fan stop the outdoor unit s fan stops 60 seconds after the compressor 87
- Forced cooling operation control 88
- Wiring error check control 89
- Breakdown self diagnosis function three digits alphanumeric code 91
- Self diagnosis display 91
- Error code 92
- Disassembly of parts 108
- Indoor control board removal procedures 108
- Remove the front grille 108
- Remove the indoor control board 108
- Wall type 108
- Cross flow fan and fan motor removal procedures 109
- Electronic controller removal procedures 109
- Remove cross flow fan and fan motor 109
- Remove main electronic controller 109
- Duct type 110
- Ceiling floor type 112
- Electronic controller removal procedure 112
- Fan motor removal procedure 112
- Front grille removal procedure 112
- Disassembly of parts 113
- Mini cassette type 113
- Outdoor unit 115
- Removing the cabinet top plate and cabinet front plate 115
- All parts are compliant with eu rohs legislation 120
- All parts are supplied from phaam malaysia vendor code 061 120
- Marked parts are recommended to be kept in stock 120
- Models cs me7dkeg cs me7dkdg cs e9dkew cs e9dkdw cs e12dkew cs e12dkdw 120
- Replacement parts list indoor unit 120
- All parts are compliant with eu rohs legislation 122
- All parts are supplied from phaam malaysia vendor code 061 122
- Marked parts are recommended to be kept in stock 122
- Models cs e15dkew cs e15dkdw 122
- Replacement parts list indoor unit 122
- All parts are compliant with eu rohs legislation 124
- All parts are supplied from phaam malaysia vendor code 061 124
- Marked parts are recommended to be kept in stock 124
- Models cs e18dkew cs e18dkdw 124
- Replacement parts list indoor unit 124
- All parts are compliant with eu rohs legislation 126
- All parts are supplied from acd in japan 126
- Marked parts are recommended to be kept in stock 126
- Models cs me10dd3eg cs e15dd3ew cs e18dd3ew 126
- Replacement parts list indoor unit 126
- All parts are compliant with eu rohs legislation 128
- All parts are supplied from phaam malaysia vendor code 061 128
- Marked parts are recommended to be kept in stock 128
- Models cs me10dteg cs e15dtew cs e18dtew 128
- Replacement parts list indoor unit 128
- All parts are compliant with eu rohs legislation 131
- All parts are supplied from phaam malaysia vendor code 061 131
- Marked parts are recommended to be kept in stock 131
- Models cs e15db4ew cs e18db4ew 131
- Replacement parts list indoor unit 131
- All parts are compliant with eu rohs legislation 133
- All parts are supplied from phaam malaysia vendor code 061 133
- Marked parts are recommended to be kept in stock 133
- Model cz bt12de front grille complete 133
- Replacement parts list indoor unit front grille 133
- Models cu 3e18ebe 135
- Replacement parts list outdoor unit 135
- Acd printed in japan 136
- Marked parts are recommended to be kept in stock 136
- Parts other the operation manual and installation manual are parts for rohs 136
