2.3. OUTDOOR UNIT
Outdoor Air Temperature
Control
Deice Operation
Low Operation Frequency
Protection Control
IPM (Power Transistor)
Overheating Protection Control
Compressor Overheating
Prevention Control
Total Running Current Control
Time Delay Safety Control
30 seconds Forced Operation
Overload Protection
5
CS-XE9DKE CU-XE9DKE / CS-XE12DKE CU-XE12DKE
