Содержание
- Air conditioner 1
- Cs xe9eke cu xe9eke cs xe12eke cu xe12eke 1
- Table of contents 1
- Carry out test running to confirm that no abnormality occurs after the servicing then explain to user the operation care and maintenance as stated in instructions please remind the customer to keep the operating instructions for future reference 3
- Read the following safety precautions carefully before perform any servicing electrical work must be installed or serviced by a licensed electrician be sure to use the correct rating of the power plug and main circuit for the model installed the caution items stated here must be followed because these important contents are related to safety the meaning of each indication used is as below incorrect installation or servicing due to ignoring of the instruction will cause harm or damage and the seriousness is classified by the following indications 3
- Safety precautions 3
- The items to be followed are classified by the symbols 3
- Attention 4
- Cs xe9eke cu xe9eke 5
- Specifications 5
- Note specifications are subject to change without notice for further improvement 6
- Cs xe12eke cu xe12eke 7
- Specifications are subject to change without notice for further improvement 8
- Features 9
- Indoor unit 10
- Location of controls and components 10
- Outdoor unit 10
- Remote control 10
- Indoor unit 17
- Printed circuit board 17
- Indicator 19
- Diagnosis 20
- Outdoor unit 21
- If an awning is built over the unit to prevent direct sunlight or rain be careful that heat radiation from the condenser is not obstructed there should not be any animal or plant which could be affected by hot air discharged keep the spaces indicated by arrows from wall ceiling fence or other obstacles do not place any obstacles which may cause a short circuit of the discharged air if piping length is over the rated length additional refrigerant should be added as shown in the table 23
- Installation instruction 23
- Select the best location 23
- There should not be any heat source or steam near the unit there should not be any obstacles blocking the air circula tion a place where air circulation in the room is good a place where drainage can be easily done a place where noise prevention is taken into consideration do not install the unit near the door way ensure the spaces indicated by arrows from the wall ceiling fence or other obstacles recommended installation height for indoor unit shall be at least 2 m 23
- This illustration is for explanation purposes only the indoor unit will actually face a different way 23
- How to fix installation plate 24
- Indoor unit 24
- Installing the ventilation hose 24
- To drill a hole in the wall and install a sleeve of piping 24
- Indoor unit installation 25
- Connect the cable to the indoor unit 28
- Connecting the piping 28
- Install the outdoor unit 28
- Outdoor unit 28
- Evacuation of the equipment for europe oceania destination 29
- Connect the cable to the outdoor unit 30
- Airflow direction 31
- Automatic vertical airflow direction can be set using remote control the vane swings up and down within the angles as stated above for heating mode operation the angle of the vane depends on the indoor heat exchanger temperature as figure 1 below when the air conditioner is stopped using remote control the vane will shift to close position 31
- Basic function 31
- Internal setting temperature 31
- Inverter control which equipped with a microcomputer in determining the most suitable operating mode as time passes auto matically adjusts output power for maximum comfort always in order to achieve the suitable operating mode the microcom puter maintains the set temperature by measuring the temperature of the environment and performing temperature shifting the compressor at outdoor unit is operating following the frequency instructed by the microcomputer at indoor unit that judging the condition according to internal setting temperature and intake air temperature 31
- Manual vertical airflow direction can be set using remote control the angles of the vane are as stated above and the positions of the vane are as figure 2 below when the air conditioner is stopped using remote control the vane will shift to close posi tion 31
- Once the operation starts remote control setting temperature will be taken as base value for temperature shifting processes these shifting processes are depending on the air conditioner settings and the operation environment the final shifted value will be used as internal setting temperature and it is updated continuously whenever the electrical power is supplied to the unit 31
- Operation and function 31
- There are two types of airflow vertical airflow directed by horizontal vane and horizontal airflow directed by vertical vanes 2 control of airflow direction can be automatic angles of direction is determined by operation mode heat exchanger tempera ture and intake air temperature and manual angles of direction can be adjusted using remote control 31
- Vertical airflow 31
- A purpose to provide quiet cooling operation compare to normal operation 32
- Automatic horizontal airflow direction can be set using remote control the vane swings left and right within the angles as stated below for heating mode operation the angle of the vane depends on the indoor heat exchanger temperature as fig ure 1 below 32
- B control condition a quiet operation start condition when quiet button at remote control is pressed quiet led illuminates 32
- B quiet operation stop condition 1 when one of the following conditions is satisfied quiet operation stops a powerful button is pressed b stop by off on switch c timer off activates d quiet button is pressed again 32
- Horizontal airflow 32
- Manual horizontal airflow direction can be set using remote control the angles of the vane are as stated below and the posi tions of the vane are as figure 2 above 32
- Quiet operation cooling mode cooling area of dry mode 32
- Powerful mode operation 33
- Quiet operation heating 33
- Auto restart control 34
- Off timer control 34
- On timer control 34
- Remote control signal receiving sound 34
- Auto filter cleaning 35
- Filter cleaning control 35
- Force filter cleaning 35
- Manual filter cleaning 35
- Timer filter cleaning 35
- Independent operation 36
- Simultaneous operation 36
- Ventilation control 36
- Compressor overheating prevention control 37
- Compressor protection control refrigeration cycle abnormality 37
- Ipm power transistor protection control dc peak detection 37
- Outdoor high pressure prevention control cooling and dry operations 37
- Protection control 37
- Seconds forced operation 37
- Time delay safety control 37
- Total running current control 37
- Anti freezing control cooling and dry operations 38
- Four way valve operation detection control switching abnormality between cool 38
- Indoor intake air temperature control heating operation 38
- Ing and heating 38
- Outdoor air temperature control 38
- Auto off on button 39
- Servicing mode 39
- Current setting 40
- Remote control number switch mode 40
- Various setting mode 40
- Ventilation control setting mode 40
- Choose the operation setting by pressing auto off on button 41
- Filter cleaning operation setting 41
- If there is no operation or receives any remote control signal within 5 minutes the setting mode quits 41
- Individual correspondence mode 41
- Select remote control transmission code 42
- Demo mode 43
- Refrigeration cycle system 44
- Troubleshooting guide 44
- Carry out the measurements of pressure electric current and temperature fifteen minutes after an operation is started 45
- Relationship between the condition of the air conditioner and pres sure and electric current 45
- Breakdown self diagnosis function 46
- Self diagnosis function three digits alphanumeric code 46
- Changed from one beep to four beep sounds 47
- Error codes table 47
- Note o frequency measured and fan speed fixed 47
- The memory data of error code is erased when the power supply is cut off or press the auto switch until beep sound heard follow ing by pressing the check button at remote controller although operation forced to stop when abnormality detected emergency operation is possible for certain errors refer to error codes table by using remote controller or auto switch at indoor unit however the remote controller signal receiving sound is 47
- Error during filter cleaning operation 48
- Error during ventilation operation 48
- Initial operation after installation 48
- Movable front panel malfunction 48
- Disassembly and assembly instructions 49
- Indoor electronic controller auto cleaning cross flow fan and fan motor removal procedures 49
- Caution the particular piece bottom may drop out while removing 53
- Filter cleaning device complete removal instructions 53
- Ventilation device removal instructions 55
- Gear removal instructions 56
- Cs xe9eke cu xe9eke 59
- Technical data 59
- Cs xe12eke cu xe12eke 67
- Condition indoor temperature 27 c 19 c outdoor temperature 35 c 24 c 75
- Cs xe12eke cu xe12eke 75
- Cs xe9eke cu xe9eke 75
- Sensible capacity chart 75
- Tc total cooling capacity kw shc sensible heat capacity kw ip input power kw 75
- Exploded view and replacement parts list 76
- Indoor unit 76
- Note all parts are supplied from phaam malaysia vendor code 061 o marked parts are recommended to be kept in stock 77
- Outdoor unit 78
- Note all parts are supplied from phaam malaysia vendor code 061 o marked parts are recommended to be kept in stock 79
- Phaam printed in malaysia ssyw0603 02 79
