![i-mop IMOPXL.FCT.1107C [11/31] Standard parts](/views2/1833029/page11/bgb.png)
STANDARD PARTS
Tennant i- mop XL (05- 2017)
11
CONTROL CONSOLE ASSEMBLY
Ref. Part No. Serial Number Description Qty.
1 1232438 (300000- ) Control Assy, Unit 1
Y
2 1232684 (300000- ) Knob, Cntrl 1
Y
3 N/A (300000- ) Hexagon Socket Set Screw M4 x 8 1
Y
4 N/A (300000- ) Fixation Insert T urning Button 1
Y
5 N/A (300000- ) M4x25 Countersunk Screw Stainless Steel 1
Y
6 N/A (300000- ) Support Plastic Bush Top Al Sticker Long 1
Y
7 N/A (300000- ) Rubber Block Water Save Adjustment Hole[A] 1
Y
8 N/A (300000- ) M4x20 Countersunk Screw Stainless Steel 1
Y
9 N/A (300000- ) Support Plastic Bush Top Al Sticker Short 1
Y
10 1232686 (300000- ) Decal, Instr 1
Y
11 N/A (300000- ) Water Save Button 1
Y
12 N/A (300000- ) Top Housing Control Unit Color: White [A] 1
Y
13 1232669 (300000- ) Circuitboard, Cntrl 1
Y
14 N/A (300000- ) Switch Wire Clamp, Color: Black 1
Y
15 N/A (300000- ) Screw M3x12 Crosshead Selftapping Bl- ni Sst 3
Y
16 N/A (300000- ) Screw 4x10 1
Y
17 N/A (300000- ) Screw M4x35 Crosshead, Standard Thread Sst 2
Y
18 N/A (300000- ) Handle Grip Without Protrusion, Color: Gray (P431C) 2
Y
19 N/A (300000- ) End Cap Grip, Color: Blue (P312C) 2
Y
20 N/A (300000- ) Screw M4x12 Crosshead, Standard Thread Sst 2
Y
21 N/A (300000- ) Rear Housing Control Unit Color: White 1
Y
22 N/A (300000- ) Power Switch Control Unit Omoron 1
Y
23 N/A (300000- ) Rubber Block 15x10x5mm Injected 1
Y
24 N/A (300000- ) Handle Control Unit Color: Blue
Y
25 N/A (300000- ) Front Housing Control Unit Color: White 1
Y
26 N/A (300000- ) Assy Al Plate Sticker Imop [Handle] 1
Y
27 N/A (300000- ) Spring Switch Lever Dia 0.8mm 1
Y
28 N/A (300000- ) Magnet Ring Easy Scrub 1
Y
29 N/A (300000- ) Screw Wn 5451 25x10 Ejot Delta Pt 2
Y
30 N/A (300000- ) Plastic Washer 9x4x1mm 2
Y
31 N/A (300000- ) On/Off Switch Wires / L=250mm 1
