3.1. Product Specification
3 Specification
3.1.1. CS-F50DB4E5 CU-L50DBE8
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F50DB4E5 CU-L50DBE8
Panel CZ-BT03P
Remote CZ-RD513C (Wired)
Control CZ-RL513B (Wireless)
Cooling Capacity kW 14.0
BTU/h 47,700
Heating Capacity kW 16.0
BTU/h 54,600
Refrigerant Charge-less m 30
Standard Air Volume for High, m
3
/min Hi 32 Me 29 Lo 25 Hi 98
Medium and Low Speed cfm 1130 970 850 3460
Outside Dimension (H x W x D) mm 288 x 840 x 840 1340 x 900 x 320
inch 11-11/32 x 33-1/24 x 33-1/24 52-7/8 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 28.5 (63) 105 (231)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.53 (3/8) Flared Type
Drain mm O.DØ20 I.D Ø 20 x 1
Compressor Type, Number of Set - Hermetic - 2P (Rotary), 2
Starting Method - DC-INV control
Motor Type - 4-pole single phase brushless motor
Rated Output kW - 3.8
Fan Type, Number of Set Turbo fan-1 Propeller fan-1
Motor Type 8-pole DC brushless motor 6-pole single phase induction motor
Rated Output kW 0.06 0.07 x 2
Air-heat Exchanger (Row x Stage x FPI) Louver-fin type (2 x 12 x 21) Corrugate-fin type (2 x 51 x 18)
Refrigerant Control - Exp. Value
Refrigerant Oil (Charged) cm
3
- FV50S (1200)
Refrigerant (Charged) R410A kg (oz) - 3.50 (123)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Safety Devices Internal protector for compressor, Internal thermostat for fan motor,
Crankcase heater, High pressure switch, Current transformer
Noise Level dB (A) Hi 47 Lo 42 Cooling 54, Heating 56
Power level dB Cooling : Hi 62 Lo 57
Heating : Hi 62 Lo 57
Cooling 68, Heating 70
Moisture Removal L/h 9.0
EER W/W 3.01
COP W/W 3.41
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Condition by JIS-B8615
Volts V 380 400 415
Phase 3N 3N 3N
Power Consumption kW Cool 4.65 4.65 4.65
Heat 4.69 4.69 4.69
Running Current A Cool 7.30 7.1 7.0
Heat 7.4 7.2 7.1
Starting Current A 7.4 7.2 7.1
Power Factor % Cool 97 95 92
Heat 96 94 92
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3N~380V, 400V, 415V 50Hz
12
CS-F50DB4E5 CU-L50DBE8
