2.4. WH-SDF14C6E5 WH-UD14CE5-A
Item Unit Outdoor Unit
Performance Test Condition EUROVENT
Heating Capacity kW 14.00
BTU/h 47800
kJ/h 50400
COP W/W 4.50
BTU/hW 15.4
Noise Level dB (A) 51
Power Level dB 68
Air Flow
m
3
/min (ft
3
/min)
84.0 (2970)
Refrigeration Control Device Expansion Valve
Refrigeration Oil
cm
3
FV50S (1200)
Refrigerant (R410A) kg (oz) 2.75 (97.1)
Dimension Height mm (inch) 1340 (52-3/4)
Width mm (inch) 900 (35-7/16)
Depth mm (inch) 320 (12-19/32)
Net Weight kg (lbs) 106 (234)
Pipe Diameter Liquid mm (inch) 9.52 (3/8)
Gas mm (inch) 15.88 (5/8)
Standard Length m (ft) 7 (23.0)
Pipe Length Range m (ft) 3 (9.8) ~ 40 (131.2)
I/D & O/D Height Difference m (ft) 30 (98.4)
Additional Gas Amount g/m (oz/ft) 50 (0.5)
Refrigeration Charge Less m (ft) 30 (98.4)
Compressor Type Hermetic Motor
Motor Type Brushless (4-poles)
Rated Output kW 3.00
Fan Type Propeller Fan
Material PP
Motor Type Induction (8-poles)
Input Power W —
Output Power W 60
Fan Speed rpm 540 (Top Fan) 580 (Bottom Fan)
Heat Exchanger Fin material Aluminium (Pre Coat)
Fin Type Corrugated Fin
Row × Stage × FPI 2 × 51 × 18
Size (W × H × L) mm 881.5 × 1295.4 × 44
Item Unit
Power Source (Phase, Voltage, Cycle) ø Single
V 230
Hz 50
Input Power kW 3.11
Maximum Input Power For Heat Pump System kW 5.52
Maximum Input Power For Internal Heater
(Internal Heater + Tank Heater)
kW 6.00 (9.00)
Starting Current A 14.1
Running Current A 14.1
Maximum Current For Heat Pump System A 25.0
Maximum Current For Internal Heater
(Internal Heater + Tank Heater)
A 26 (39)
Power Factor % 96
Power factor means total figure of compressor and outdoor fan motor.
