– 6
All current-conducting parts in the working
area must be protected against jet water.
The appliance may only be connected to an
electrical supply which has been installed in
accordance with IEC 60364.
The appliance may only be connected to al-
ternating current. The voltage must corre-
spond with the type plate on the appliance.
For safety reasons, we recommend that you
operate the appliance only via a earth-leak-
age circuit breaker (max. 30 mA).
Cleaning operations which produce oily
waste water, e.g. engine washes, underbody
washes, may only be carried out using wash-
ing stations equipped with an oil separator.
Caution
Safety devices protect the user and must not be
modified or bypassed.
The appliance switch prevents unintentional op-
eration of the appliance.
This lock locks the lever of the trigger gun and
prevents the inadvertent start of the appliance.
The overflow valve prevents the permissible
working pressure from being exceeded.
If the lever on the trigger gun is released the
pressure switch turns off the pump, the high-
pressure jet is stopped. If the lever is pulled the
pump is turned on again.
Caution
Create stability for the appliance prior to all work
on or with the appliance to prevent accidents or
damage.
– The stability of the appliance is warranted
when it is placed onto an even surface.
The scope of delivery of your appliance is illus-
trated on the packaging. Check the contents of
the appliance for completeness when unpack-
ing.
In the event of missing accessories or any trans-
port damage, please contact your dealer.
These operating instructions describe the maxi-
mum equipment. Depending on the model, there
are differences in the scopes of delivery (see
packaging).
Illustrations on Page 2
1 Quick coupling for high pressure hose
2 High pressure connection
3 Appliance switch "0/OFF“/ „I/ON“
4 Storage hook for high pressure hose and
mains connection cable
5 Storage for spray lance
6 Storage for trigger gun
7 Water connection with integrated sieve
8 Detergent suction hose (with sieve)
9 Coupling element for water connection
10 Mains cable with mains plug
11 Bearing wheel
12 Trigger gun
13 Lock trigger gun
14 Key to detach the high pressure hose from
the trigger gun
15 High pressure hose
Optional accessories
16 Rotary washing brush
17 Washing brush
18 Spray lance with high pressure nozzle
19 Spray lance with Dirtblaster
20 Spray lance with pressure regulation (Vario
Power)
21 Transport handle
22 Carrying handle
23 Transport handle, detachable
24 Detergent Tank
25 Accessory net
Special accessories expand the possibilities of
using your appliance. Please contact your
KÄRCHER dealer for further information.
Safety Devices
Power switch
Lock trigger gun
Overflow valve with pressure switch
Prerequisites for the appliance's
stability
Operation
Scope of delivery
Description of the Appliance
Special accessories
13EN
