145
<Model: WH-UD12CE5-A WH-UD14CE5-A WH-UD16CE5-A>
REF. NO. DESCRIPTION & NAME QTY. WH-UD12CE5-A WH-UD14CE5-A WH-UD16CE5-A REMARKS
1 BASE PAN ASS’Y 1 CWD52K1200 ←←
2 COMPRESSOR 1 5JD420XAA22 ←←O
3 ANTI-VIBRATION BUSHING 3 CWH50055 ←←
4 NUT FOR COMP. MOUNT. 3 CWH561049 ←←
4a PACKING 3 CWB811017 ←←
5 CRANKCASE HEATER 1 CWA341053 ←←
6 CONDENSER COMPLETE 1 CWB32C2983 ←←
7 HIGH PRESSURE SENSOR 1 CWA50C2570 ←←
8 DISCHARGE MUFFLER 1 CWB121014 ←←
9 PRESSURE SWITCH 1 CWA101013 ←←
10 3-WAYS VALVE (GAS) 1 CWB011251 ←←
11 4-WAYS VALVE 1 CWB001046 ←←
12 3-WAYS VALVE (LIQUID) 1 CWB011292 ←←
13 STRAINER 2 CWB111032 ←←
19 ACCUMULATOR ASS’Y 1 CWB131026A ←←
20 SOUND PROOF MATERIAL - COMP 1 CWG302265 ←←
21 SOUND PROOF MATERIAL 1 CWG302266 ←←
22 SOUND-PROOF BOARD ASS’Y 1 CWH15K1019 ←←
23 V-COIL COMPLETE - 4-WAYS VALVE 1 CWA43C2169J ←←O
24 V-COIL COMPLETE - EXP. VALVE 1 CWA43C2385 ←←O
25 SENSOR-OD TEMP./COIL 1 CWA50C2730 ←←
26 SENSOR-COMP.DISCHARGE 1 CWA50C2576 ←←
27 SENSOR-COMP. TOP 1 CWA50C2629 ←←
27a SENSOR-COMP. DEF. 1 CWA50C2577 ←←
28 CABINET REAR PLATE 1 CWE02C1059 ←←
29 CONTROL BOARD CASING 1 CWH10K1049 ←←
31 TERMINAL BOARD ASS’Y 1 CWA28K1213 ←←
36 ELECTRONIC CONTROLLER (CAPACITOR) 1 CWA746169 ←←O
38 ELECTRONIC CONTROLLER (NOISE FILTER) 1 CWA745446 ←←O
44 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C4835R CWA73C4836R CWA73C4837R O
46 REACTOR 2 G0C592J00004 ←←
48 TERMINAL COVER 1 CWH171039A ←←
49 NUT FOR TERMINAL COVER 1 CWH7080300J ←←
50 BRACKET FAN MOTOR 1 CWD54K1024 ←←
50a SCREW-BRACKET FAN MOTOR 2 CWH551040J ←←
53 FAN MOTOR 1 EHDS80AAC ←←O
54 FAN MOTOR 1 EHDS80BAC ←←O
54a SCREW-FAN MOTOR 8 CWH551016J ←←
55 PROPELLER FAN 2 CWH00K1006 ←←
56 NUT for PROPELLER FAN 2 CWH561051 ←←
57 CABINET FRONT PLATE 1 CWE061098A ←←
58 DISCHARGE GRILLE 2 CWE201073 ←←
59 CABINET SIDE PLATE 1 CWE04K1023A ←←
60 WIRE NET 1 CWD041103A ←←
61 CABINET TOP PLATE COMPLETE 1 CWE03C1021 ←←
62 ACCESSORY COMPLETE 1 CWH82C1535 ←←
64 PIPE COVER (FRONT) 1 CWD601074A
←←
65
PIPE COVER (BACK) 1 CWD601075A ←←
66 CABINET FRONT PLATE COMPLETE 1 CWE06C1091 ←←
67 HANDLE 2 CWE161008 ←←
68 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1541 ←←
70 EXPANSION VALVE 1 CWB051028 ←←
