12
Item Unit
Starting Current
A 7.2
Running Current
A
Cooling: 7.2
Heating: 5.7
Max. Current / Max. Input Power Heatpump Unit
(Heatpump Unit + Back-up Heater)
A / kW 9.9 / 6.59 (Separate ELCB)
Back-up Heater: Max. Current / Max. Input Power
A / kW 13.0 / 9.00
Tank Heater [1 Phase, 230V]: Max. Current / Max.
Input Power
A / kW 13.0 / 3.00
Power Factor
%
Cooling: 97
Heating: 96
Power factor means total figure of compressor and outdoor fan motor.
Number of core -
Power Cord
Length m (ft) -
Thermostat
Electronic Control
Protection Device
Electronic Control
Item Unit Indoor Unit
Performance Test Condition
EUROVENT
Outdoor Ambient °C
Cooling: 16 ~ 43
Heating: -20 ~ 35
Operation Range
Water Outlet °C
Cooling: 5 ~ 20
Heating: 25 ~ 55
Internal Pressure Differential
kPa
Cooling: 18.0
Heating: 30.2
dB (A)
Cooling: 30
Heating: 30
Noise Level
Power Level dB
Cooling: 43
Heating: 43
Height mm (inch) 892 (35-1/8)
Width mm (inch) 502 (19-3/4)
Dimension
Depth mm (inch) 353 (13-29/32)
Net Weight
kg (lbs) 52 (115)
Liquid mm (inch) 9.52 (3/8)
Refrigerant Pipe Diameter
Gas mm (inch) 15.88 (5/8)
Inlet mm (inch) 28 (1-3/32)
Water Pipe Diameter
Outlet mm (inch) 28 (1-3/32)
Water Drain Hose Inner Diameter
mm (inch) 15.00 (19/32)
Motor Type Capacitor Run Induction Motor (5 μF)
No. of Speed 3
Pump
Input Power W 180
Type Brazed Plate
No. of Plates 80
Size (H x W x L) mm 130 × 93 × 325
Hot Water Coil
Water Flow Rate l/min (m
3
/h)
Cooling: 35.0 (2.1)
Heating: 45.9 (2.8)
Pressure Relief Valve Water Circuit
kPa Open: 190, Close: 183 and below
Flow Switch
Magnetic Lead Switch
Protection Device
A Residual Current Circuit Breaker (1 Phase: 40 & 3 Phase: 25)
Volume I 10
Expansion Vessel
MWP bar 1
Capacity of Integrated Electric Heater
kW 9.00
Note:
Cooling capacities are based on outdoor air temperature of 35°C Dry Bulb with controlled indoor water inlet
temperature of 12°C and water outlet temperature of 7°C.
Heating capacities are based on outdoor air temperature of 7°C Dry Bulb (44.6°F Dry Bulb), 6°C Wet Bulb
(42.8°F Wet Bulb) with controlled indoor water inlet temperature of 30°C and water outlet temperature of 35°C.
Specification are subjected to change without prior notice for further improvement.
