10
Indoor CS-HE12NKE
Model
Outdoor CU-HE12NKE
Inner Diameter mm 16
Drain Hose
Length mm 650
Fin Material Aluminium (Pre Coat)
Fin Type Slit Fin
Row × Stage × FPI 2 × 17 × 21
Indoor Heat
Exchanger
Size (W × H × L) mm 636.5 × 357 × 25.4
Fin Material Aluminium
Fin Type Corrugate Fin
Row × Stage × FPI 2 × 28 × 17
Outdoor Heat
Exchanger
Size (W × H × L) mm 36.4 × 588 × 856.3:827.7
Material Polypropelene
Air Filter
Type One-touch
Power Supply Indoor
Power Supply Cord A Nil
Thermostat Electronic Control
Protection Device Electronic Control
Dry Bulb Wet Bulb
Maximum 32 23
Cooling
Minimum 16 11
Maximum 30 —
Heating
Minimum 16 —
Maximum 10 —
Indoor
Operation
Range
+8/10°C
HEAT
Minimum 8 —
Maximum 43 26
Cooling
Minimum 16 11
Maximum 24 18
Heating
Minimum -15 —
Maximum — —
Outdoor
Operation
Range
+8/10°C
HEAT
Minimum -15 —
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb)
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb)
3. Heating low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor 2/1°C.
4. Heating extreme low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor -7/-8°C.
5. Specifications are subjected to change without prior notice for further improvement.
6. Maximum heating capacity shown are the values based on powerful operation.
7. If the EUROEVENT Certified models can be operated under the “extra-low” temperature condition, -7°C DB and -8°C WB temperature with
rated voltage 230V shall be used.
8. The annual consumption is calculated by multiplying the input power by an average of 500 hours per year in cooling mode.
