9
Indoor CS-HE12NKE
Model
Outdoor CU-HE12NKE
Type Cross-flow Fan
Material ASG33
Motor Type Transistor (8-poles)
Input Power W 44.9
Output Power W 40
Cool/Fan rpm 690
QLo
Heat rpm 870
Cool/Fan rpm 740
Lo
Heat rpm 930
Cool/Fan rpm 930
Me
Heat rpm 1100
Cool/Fan rpm 1130
Hi
Heat rpm 1270
Cool/Fan rpm 1200
Indoor Fan
Speed
SHi
Heat rpm 1340
Type Propeller Fan
Material PP
Motor Type DC Type (8-poles)
Input Power W —
Output Power W 40
Cool rpm 860
Outdoor Fan
Speed Hi
Heat rpm 890
Moisture Removal L/h (Pt/h) 2.0 (4.2)
Cool/Fan m
3
/min (ft
3
/min) 7.55 (265)
QLo
Heat m
3
/min (ft
3
/min) 9.86 (348)
Cool/Fan m
3
/min (ft
3
/min) 8.19 (290)
Lo
Heat m
3
/min (ft
3
/min) 10.64 (375)
Cool/Fan m
3
/min (ft
3
/min) 10.7 (378)
Me
Heat m
3
/min (ft
3
/min) 12.82 (453)
Cool/Fan m
3
/min (ft
3
/min) 13.2 (465)
Hi
Heat m
3
/min (ft
3
/min) 15.0 (530)
Cool/Fan m
3
/min (ft
3
/min) 14.11 (498)
Indoor Airflow
SHi
Heat m
3
/min (ft
3
/min) 15.91 (562)
Cool/Fan m
3
/min (ft
3
/min) 34.4 (1215)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 35.6 (1255)
Control Device Expansion Valve
Refrigerant Oil cm
3
FV50S (450)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.40k (49.4)
Height(I/D / O/D) mm (inch) 295 (11-5/8) / 622 (24-1/2)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 824 (32-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 255 (10-1/16) / 299 (11-25/32)
Weight Net (I/D / O/D) kg (lb) 10 (22) / 38 (84)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8)
Standard length m (ft) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 5.0 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6)
