9
Indoor CS-NE12NKE CS-XE12NKE-5 CS-QE12NKE CS-WE12NKE
Model
Outdoor CU-NE12NKE CU-QE12NKE
Type Cross-flow Fan
Material ASG33
Motor Type Transistor (8-poles)
Input Power W 44.9
Output Power W 40
Cool/Fan rpm 710
QLo
Heat rpm 860
Cool/Fan rpm 760
Lo
Heat rpm 920
Cool/Fan rpm 940
Me
Heat rpm 1060
Cool/Fan rpm 1120
Hi
Heat rpm 1200
Cool/Fan rpm 1200
Indoor Fan
Speed
SHi
Heat rpm 1280
Type Propeller Fan
Material PP
Motor Type DC Type (8-poles)
Input Power W —
Output Power W 40
Cool rpm 880
Outdoor Fan
Speed Hi
Heat rpm 860
Moisture Removal L/h (Pt/h) 2.0 (4.2)
Cool/Fan m
3
/min (ft
3
/min) 8.00 (280)
QLo
Heat m
3
/min (ft
3
/min) 10.04 (355)
Cool/Fan m
3
/min (ft
3
/min) 8.68 (305)
Lo
Heat m
3
/min (ft
3
/min) 10.86 (380)
Cool/Fan m
3
/min (ft
3
/min) 11.13 (390)
Me
Heat m
3
/min (ft
3
/min) 12.76 (450)
Cool/Fan m
3
/min (ft
3
/min) 13.6 (480)
Hi
Heat m
3
/min (ft
3
/min) 14.7 (520)
Cool/Fan m
3
/min (ft
3
/min) 14.7 (520)
Indoor Airflow
SHi
Heat m
3
/min (ft
3
/min) 15.75 (555)
Cool/Fan m
3
/min (ft
3
/min) 32.9 (1160)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 32.1 (1135)
Control Device Expansion Valve
Refrigerant Oil cm
3
FV50S (450)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.10k (38.8)
Height(I/D / O/D) mm (inch) 295 (11-5/8) / 622 (24-1/2)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 824 (32-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 255 (10-1/16) / 299 (11-25/32)
Weight Net (I/D / O/D) kg (lb) 10 (22) / 36 (79)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8)
Standard length m (ft) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 5.0 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6)
