Panasonic CS-E15CKP / CU-E15CKP5 Сервис мануал онлайн
1 Features 2
2 Functions
3
3 Product Specifications
6
4 Dimensions
8
5 Refrigeration Cycle Diagram
10
6 Block Diagram
11
7 Wiring Diagram
12
8 Operation Details
13
9 Operating Instructions
38
© 2003 Matsushita Industrial Corp. Sdn. Bhd.
(11969-T). All rights reserved. Unauthorized copying
and distribution is a violation of law.
CS-E15CKP CU-E15CKP5
10 Installation And Servicing Air Conditioner Using R410A 46
11 Installation Instructions
57
12 Servicing Information
66
13 Technical Data
75
14 Exploded View
77
15 Replacement Parts List
78
16 Exploded View
79
17 Replacement Parts List
80
18 Electronic Circuit Diagram
81
Room Air Conditioner
CONTENTS
Page Page
Order No: MAC0302006C8
Содержание
- Contents 1
- Cs e15ckp cu e15ckp5 1
- Page page 1
- Room air conditioner 1
- Features 2
- Airflow direction control 3
- Check point 3
- Clock setting 3
- Functions 3
- Indoor fan speed selection 3
- Ion mode operation off on 3
- Operation mode selection 3
- Operation off on 3
- Powerful mode operation 3
- Quiet mode operation off on 3
- Remote control 3
- Reset point 3
- Room temperature setting 3
- Time timer setting 3
- Timer operation selection 3
- Timer operation set cancel 3
- Automatic and 5 manual horizontal airflow directions 4
- Automatic and 5 manual indoor fan speeds 4
- Automatic and 5 manual vertical airflow directions 4
- Automatic operation switch 4
- Automatic restart control 4
- Delay on timer and off timer 4
- Five operation modes 4
- Indoor unit 4
- Ionizer control 4
- Microcomputer controlled room temperature control 4
- Operation indication lamps led 4
- Powerful mode 4
- Quiet mode 4
- Outdoor unit 5
- Product specifications 6
- Specifications are subject to change without notice for further improvement 7
- Basic function 13
- Internal setting temperature 13
- Inverter control which equipped with a microcomputer in determining the most suitable operating mode as time passes automatically adjust output power for maximum comfort always in order to achieve the suitable operating mode the microcomputer maintains the set temperature by measuring the temperature of the environment and performing temperature shifting the compressor at outdoor unit is operating following the frequency instructed by the microcomputer at indoor unit that judging the condition according to internal setting temperature and intake air temperature 13
- Once the operation starts remote controller setting temperature will be taken as base value for temperature shifting processes these shifting processes are depending on the air conditioner settings and the operation environment the final shifted value will be used as internal setting temperature and it is updated continuously whenever the electrical power is supplied to the unit 13
- Operation details 13
- Table a auto operation mode setting 13
- Table b outdoor air temperature shifting 13
- Table c powerful mode shifting 14
- Table d fan speed shifting 14
- Table e start up shifting 14
- Table f soft dry mode shifting 14
- After the initial operation the instructed frequency will change or shift from initial frequency according to the judgment on temperature different from sampling refer to the table on shifting frequency zone 15
- For normal start of operation including thermo off deice resuming and remote controller on off starts the compressor starts to operate at frequency no 8 values of 30hz and 32hz for e9ckp and e12ckp e15ckp respectively for 60 seconds 15
- Frequency instruction for compressor operation 15
- From the internal sampling the temperature different intake air temperature internal setting temperature will be used to judge the zone on which the frequency to be instructed for the initial operation of compressor refer to table on initial frequency zone 15
- Operation of compressor is based on instructed frequency continuously from indoor unit s microcomputer after performing temperature sampling and judgment 15
- The frequency to be judged and instructed however starts to judge once the air conditioner operated and the judgment will continue every 30 seconds until it is stopped by all kinds of compressor off conditions this judgment is based on the internal temperature sampling that involving internal setting temperature and intake air temperature 15
- There are total 30 different frequency values which listed as table on frequency number to be instructed based on the temperature judgment 15
- Besides the range of operation frequency will change according to the setting environment as listed below 16
- Remark 16
- A starting frequency 17
- A the frequency judged changes from frequency number decreasing zones zone no 0 or 1 or 2 or 3 to frequency number increasing zones zone no 5 or 6 or 7 or 8 and vice verse 17
- B frequency judged falls on zone 7 or 8 shift to frequency max 17
- B the frequency judged falls on frequency shifting zone number 0 or 1 shift to frequency min at cooling mode operation 17
- C 90 seconds frequency instruction limit 17
- C the frequency judged falls on frequency shifting zone number 4 no shifting in frequency number at cooling mode operation 17
- D frequency judged falls on zone 4 no shifting 17
- D the frequency judged falls on frequency shifting zone number 7 or 8 shift to frequency max at automatic fan speed 17
- E frequency no changes from no increasing zones to no decreasing zones 17
- F frequency judged falls on zone 0 or 1 shift to frequency min 17
- G normal initial operation starts 60 s 17
- H maximum frequency for normal cooling operation 17
- I minimum frequency for normal cooling operation 17
- The frequency judgment will perform every 30 seconds nevertheless the frequency is instructed to outdoor compressor after every 90 seconds except when either one of the below conditions is met 17
- The instructed frequency is the value referred by the frequency number which resulted from previous instructed frequency number with the numbers of frequency numbers to be shifted in table on frequency number 17
- Indoor fan motor operation 18
- There are 31 fan speed numbers assigned for different fan speed operation at designed conditions as shown in below table the fan speed can be set manually using remote control 5 speeds for cooling mode lo me me me hi 5 speeds for heating lo me me me shi or let it automatically changes depending on the operation and its environment 18
- A during cooling operation if all the following conditions occur indoor fan speed will be shifted to shi internally 19
- Cooling mode automatic indoor fan speed 19
- Heating mode indoor fan motor operation anti cold draft control 19
- I indoor intake air temperature 19
- Ii instructed frequency 39 hz e9ckp or 52 hz e12ckp e15ckp 19
- Iii remote controller setting temperature 16 c 19
- Indoor fan speed varies in accordance to indoor heat exchanger temperature based on type of air volume and direction as shown below 19
- Iv remote controller setting fan speed hi 19
- Manual fan speed 19
- Minutes 19
- The automatic fan speed for cooling operation is as shown in below patterns a b c h with each pattern 10 seconds the fan speed for each level x or y or z is as below table 19
- V outdoor air temperature 19
- Vi operation starts 19
- Outdoor fan motor operation 20
- Airflow direction 21
- Automatic horizontal airflow direction can be set using remote controller the vane swings left and right within the angles as stated below for heating mode operation the angle of the vane depends on the indoor heat exchanger temperature as figure 1 below 21
- Automatic vertical airflow direction can be set using remote controller the vane swings up and down within the angles as stated above for heating mode operation the angle of the vane depends on the indoor heat exchanger temperature as figure 1 below when the air conditioner is stopped using remote controller the vane will shift to close position 21
- Control of airflow direction can be automatic angles of direction is determined by operation mode heat exchanger temperature and intake air temperature and manual angles of direction can be adjusted using remote controller 21
- Horizontal airflow 21
- Manual vertical airflow direction can be set using remote controller the angles of the vane are as stated above and the positions of the vane are as figure 2 below when the air conditioner is stopped using remote controller the vane will shift to close position 21
- There are two types of airflow vertical airflow directed by horizontal vane and horizontal airflow directed by vertical vanes 21
- Vertical airflow 21
- Automatic mode operation 22
- During operation mode judgment indoor fan motor with speed of lo and outdoor fan motor are running for 20 seconds to detect the indoor intake and outdoor air temperature the operation mode is decided based on below chart 22
- Manual horizontal airflow direction can be set using remote controller the angles of the vane are as stated below and the positions of the vane are as figure 2 above 22
- There is a temperature shifting on t1 t2 and t3 if the operation mode judged is changed from cooling soft dry to heating or vice verse 22
- This mode can be set using remote controller and the operation is decided by remote controller setting temperature indoor intake air temperature and outdoor air temperature 22
- Values of t1 t2 and t3 depend on remote controller setting temperature as shown in below table after the adjustment of t1 t2 and t3 values the operation mode for that particular environment and remote controller setting is judged and performed based on the above operation mode chart every 30 minutes heating mode operation will be performed however if deice operation is detected 22
- Delay on timer control 23
- Off timer control 23
- Protection control features 23
- 30 seconds forced operation 24
- However during instantaneous power failure 0 s power relay will turn off then it will turn on 3 minutes after power recover and the unit will operate as previous operation condition 24
- However if total outdoor unit running current exceeds y value compressor will be stopped immediately for three minutes 24
- However it can be stopped using remote control or auto switch at indoor unit 24
- If the running current does not exceed x value for five seconds the frequency instructed will be increased a step at one time to bigger frequency number 24
- Indoor power relay control 24
- Once the compressor starts operation it will not stop its operation for 30 seconds 24
- Power relay will turn on during operation or in progress of stopping operation although operation stops the power relay continues on for three minutes 24
- The compressor will not start for three minutes after stop of operation 24
- The first 30 minutes of cooling operation i will be applied 24
- This control is applicable to all kinds of operation mode 24
- This control is not applicable if the power supply is cut off and on again or after 4 way valve deices condition 24
- Time delay safety control 24
- Total running current control 24
- When the total outdoor unit running current ac exceeds x value the frequency instructed for compressor operation will be decreased a step to smaller frequency number 24
- A dc peak current control 25
- B overheating prevention control 25
- Compressor operation restarts after three minutes the temperature decreases to 95 c 25
- Compressor overheating prevention control 25
- If the set value is exceeded again within 30 seconds after the compressor starts the operation will restart after one minute if this condition repeats continuously for seven times all indoor and outdoor relays will be cut off 25
- If this phenomenon is continuously occurring for twice within 20 minutes all indoor and outdoor relays will be cut off 25
- Instructed frequency for compressor operation will be regulated by compressor discharge temperature the changes of frequency are as below figure 25
- Ipm power transistor prevention control 25
- Low pressure control gas leakage detection 25
- This control is applicable to all kinds of operation mode 25
- This control is not applicable for deice operation 25
- When electric current to ipm exceeds set value of 22 3 a the compressor will stop operate then operation will restart after three minutes 25
- When the conditions listed in below table occur the compressor stops and restarts after three minutes 25
- When the ipm temperature rises to 110 c compressor operation will stop immediately 25
- Auto restart control 26
- For cooling mode and soft dry mode operation the compressor operating frequency is regulated in accordance to the outdoor air temperature as shown in the diagram below this control will begin one minute after the compressor starts 26
- Low operation frequency protection control 26
- Minimum operation frequency protection control 26
- Outdoor air temperature control 26
- This control is applicable to all kinds of operation mode 26
- This type of control is not applicable during on off timer setting 26
- When all the below conditions occur minimum value freq min for the frequency instructed to compressor will change to 30 hz e9ckp and 32 hz e12ckp e15ckp for cooling mode operation and 21 hz e9ckp e12ckp e15ckp for heating mode operation 26
- When the compressor operate at frequency lower than 26 hz e9ckp or 28 hz e12ckp e15ckp for 240 minutes the operation frequency will be increased to 26 hz e9ckp or 28 hz e12ckp e15ckp for two minutes 26
- When the power supply is cut off during the operation of air conditioner the compressor will re operate within three to four minutes there are 10 patterns between 2 minutes 58 seconds and 3 minutes 52 seconds to be selected randomly after power supply resumes 26
- Deodorizing control 27
- After 420 minutes the operation restarts again from the beginning 28
- Anti fog discharge control 28
- Anti freezing control 28
- At the same time indoor fan speed increase its frequency as value of two steps up in fan speed number compared to its normal operation refer table on fan speed level and supplied voltage 28
- Compressor operating frequency will resume to normal when outdoor air temperature decrease to 37 c 28
- Compressor will resume its operation three minutes after the indoor heat exchanger is higher than 10 c 28
- High pressure at minimum frequency control 28
- If indoor heat exchanger temperature is higher than 10 c for five minutes the fan speed will return to its normal operation 28
- The operation will restart the above control whenever remote controller setting temperature or fan speed setting is changed 28
- This type of control is applicable on cooling mode and soft dry mode operation only 28
- When indoor fan speed is set at me or slower the compressor operating frequency is regulated by operation time to prevent fog discharged from indoor as shown in below table 28
- When indoor heat exchanger temperature is lower than 2 c continuously for six minutes compressor will stop operating 28
- When outdoor air temperature increases to 38 c compressor operating frequency reduces to minimum of 30 hz and 32 hz for e9ckp and e12ckp e15ckp respectively 28
- Compressor will operate at maximum of 56 hz or 68 hz for e9ckp and e12ckp e15ckp respectively if either one of the below conditions occur 29
- Deice operation control 29
- Deice operation occurs when the deice operation starting signal is generated this happens when one of he following condition occurs however the first deice operation will begin one hour after the start of heating mode operation 29
- Indoor heat exchanger temperature control 29
- Intake air temperature control 29
- Once the deice operation signal produced the instructed frequency for the operation of compressor will be set to zero hertz 0 hz for 30 seconds then deice operation starts with both indoor and outdoor fan motor and 4 way valve turn off for 30 seconds the compressor operates following the frequency as shown in below chart that depending on outdoor heat exchanger temperature and operation period with a maximum of 10 minutes and 30 seconds when the deice operation ends before back to normal operation the instructed frequency for compressor will be set to zero hertz 0 hz again and outdoor fan motor will turn on for a period of 59 seconds 29
- The compressor operating frequency is regulated in accordance to indoor heat exchanger temperature as shown in below figures 29
- This control is applicable for heating mode operation only 29
- When the intake air temperature is 10 c or above and remote controller setting fan speed is lo or lower 29
- When the intake air temperature is 30 c or above 29
- A outdoor air temperature 30
- Auto clean deice control 30
- B outdoor heat exchanger temperature 0 c for 14 minutes and 30
- C outdoor heat exchanger temperature 8 c for 10 minutes 30
- Fifteen minutes before standby operation pre deice heating operation will be performed to determine the operation decision as shown in below figure auto clean deice operation starts to operate as soon as the pre deice operation if all the below conditions occur 30
- The auto clean deice is operated for a maximum of 12 minutes as normal deice operation and the period of standby operation is maintained including the 12 minute auto clean deice operation 30
- This control is applicable for heating mode operation only and before operation starting time set by on timer control to improve heating start up operation if residual ice on outdoor heat exchanger detected 30
- Auto operation switch 31
- If power led is blinking the possible operations of the unit are hot start during deice operation operation mode judgment or delay on timer sampling 31
- If timer led is blinking there is an abnormality operation occurs 31
- Indication panel 31
- Led control frequency 31
- Lighting of 3 led base on instructed running frequency from indoor unit to compressor at cool dry heating operation 31
- When the switch is pressed between 0 to 5 seconds auto mode operation starts to function 31
- When the switch is pressed between 11 to 16 seconds and together with the signal from remote control the unit can be changed to different controlling setting a b mode 31
- When the switch is pressed between 16 to 21 seconds either h14 error detection selection mode or the remote controller s signal receiving sound can be cancelled or turned on 31
- When the switch is pressed between 5 to 8 seconds the unit is forced to operate in cooling mode 31
- When the switch is pressed between 8 to 11 seconds the unit is forced to operate in heating mode 31
- Quiet operation cooling mode cooling area of dry mode 32
- Quiet operation heating 33
- Quiet operation under soft dry operation dry area at dry mode 33
- Ionizer operation 34
- Ionizer operation case study 35
- Ionizer 38
- Operating instructions 38
- Ionizer 39
- Ionizer 41
- A chemical characteristics the chemical characteristics of r410a are similar to those of r22 in that both are chemically stable non flammable refrigerants with low toxicity however just like r22 the specific gravity of r410a gas is heavier than that of air because of this it can cause an oxygen deficiency if it leaks into a closed room since it collects in the lower area of the room it also generates toxic gas when it is directly exposed to a flame so it must be used in a well ventilated environment where it will not collect 46
- About r410a refrigerant 46
- B compositional change pseudo azeotropic characteristics r410a is a pseudo azeotropic mixture comprising the two components r32 and r125 multi component refrigerants with these chemical characteristics exhibit little compositional change even from phase changes due to vaporization 9or condensation which means that there is little change in the circulating refrigerant composition even when the refrigerant leaks from the gaseous section of the piping accordingly r410a can be handled in almost the same manner as the single component refrigerant r22 however when charging because there is a slight change in composition between the gas phase and the liquid phase inside a cylinder or other container charging should basically begin with the liquid side 46
- C pressure characteristics as seen in table 2 the gas pressure of r410a is approximately 1 times as high as that of r22 at the same refrigerant temperature which means that special r410a tools and materials with high pressure specifications must be used for all refrigerant piping work and servicing 46
- Converting air conditioners to r410a since it was declared in1974 that chlorofluorocarbons cfc hydro chlorofluorocarbons hcfc and other substances pose a destructive danger to the ozone layer in the earth s upper stratosphere 20 to 40 km above the earth measures have been taken around the world to prevent this destruction the r22 refrigerant which has conventionally been used in acs is an hcfc refrigerant and therefore possesses this ozone destroying potential international regulations the montreal protocol ozone damaging substances and the domestic laws of various countries call for the early substitution of r22 by a refrigerant which will not harm the ozone layer 46
- In acs the hfc refrigerant which has become the mainstream alternative called r410a compared with r22 the pressure of r410a is approximately 1 times as high at the same refrigerant temperature but the energy efficiency is about the same consisting of hydrogen h fluorine f and carbon c r410a is an hfc refrigerant another typical hfc refrigerant is r407c while the energy efficiency of r407c is some what inferior to that of r410a it offers the advantage of having pressure characteristics which are about the same as those of r22 and is used mainly in packaged acs 46
- Installation and servicing air conditioner using r410a 46
- Outline 46
- The characteristics of hfc r410a refrigerants 46
- 1 always replace the dryer of the outdoor unit at the same time the replacement dryer is wrapped in a vacuum pack replace it last among the refrigerating cycle parts start brazing as soon as you have opened the vacuum pack and begin the vacuuming operation within 2 hours 47
- 1 you can use the conventional r22 flaring tool if you need to buy a new tool buy the r410a type 47
- 2 use when it is necessary to detect small gas leaks 47
- After finishing the installation check to make sure there is no refrigerant gas leaking 47
- Cause the gas pressure of r410a is approximately 1 times as high as that of r22 a mistake in installation or servicing could result in a major accident it is essential that you use r410a tools and materials and that you observe the following precautions to ensure safety 47
- D r410a refrigerating machine oil conventionally mineral oil or a synthetic oil such as alkylbenzene has been used for r22 refrigerating machine oil because of the poor compatibility between r410a and conventional oils like mineral oil however there is a tendency for the refrigerating machine oil to collect in the refrigerating cycle for this reason polyester and other synthetic oils which have a high compatibility with r410a are used as refrigerating machine oil because of the high hygroscopic property of synthetic oil more care must be taken in its handling than was necessary with conventional refrigerating machine oils also these synthetic oils will degrade if mixed with mineral oil or alkylbenzene causing clogging in capillary tubes or compressor malfunction do not mix them under any circumstances 47
- Do not perform any alterations on the ac unit under any circumstances have all repair work done by a specialist incorrect repairs can result in an water leakage electric shock fire etc 47
- Do not use any refrigerant other than r410a in acs that have been used with r410a 47
- For other installation work you should have the usual tools such as screwdrivers a metal cutting saw an electrical drill a hole core drill 65 or 70 dia a tape measure a level a thermometer a clamp meter an insulation tester a voltmeter etc 47
- If any refrigerant gas leaks while you are working ventilate the room toxic gas may be generated if refrigerant gas is exposed to a direct flame 47
- In order to prevent an r410a ac from mistakenly being charged with any other refrigerant the diameter of the 3 way valve service port on the outdoor unit has been changed also to increase its ability to withstand pressure the opposing dimensions have been changed for the refrigerant pipe flaring size and flare nut accordingly when installing or servicing refrigerant piping you must have both the r410a and ordinary tools listed below 47
- Necessary tools 47
- Safety measure when installing receiving refrigerant piping 47
- Tool for installing servicing refrigerant piping 47
- When installing or transferring an ac do not allow any air or substance other than r410a to mix into the refrigeration cycle if it does the pressure in the refrigeration cycle can become abnormally high possibly causing an explosion and or injury 47
- When installing or transferring an ac follow the instructions in the installation instructions carefully incorrect installation can result in an abnormal refrigeration cycle or water leakage electric shock fire etc 47
- Because the pressure is higher for the r410a type the conventional type cannot be used 48
- Cooper tube gauge for clearance adjustment used when flaring with the conventional flaring tool clutch type 48
- Flaring tool clutch type 48
- In the r410a flaring tool the receiving hole for the clamp bar is enlarged so the clearance from the clamp bar can be set to 0 0 mm and the spring inside the tool is strengthened to increase the strength of the pipe expanding torque this flaring tools can also be used with r22 piping so we recommend that you select it if you are buying a new flaring tool 48
- Manifold gauge 48
- R410a tools 48
- The shape of the manifold ports has been changed to prevent the possibility of mistakenly charging with another type of refrigerant 48
- This gauge makes it easy to set the clearance for the copper tube to 1 1 mm from the clamp bar of the flaring tool 48
- Torque wrenches 48
- R410a tools which are usable for r22 models 50
- Piping materials 51
- Processing and connecting piping materials 51
- Refrigerant piping work 51
- A check to make sure there are no scratches dust etc on the flare and union 52
- A sheathed copper pipes and copper element pipes when using these pipes check to make sure that they are the stipulated thickness for flare nuts be sure to used the same nut that is used on the ac unit 52
- B align the flared surface with the axial center of the union 52
- Because the gas pressure of r410a is approximately 1 times as high as that of r22 copper pipes with the thickness shown in table 10 and with minimal impurities must be used care must also be taken during storage to ensure that pipes are not crushed deformed or scratched and that no dust moisture or other substance enters the pipe interior when storing sheathed copper pipes or plain copper pipes seal the openings by pinching or taping them securely 52
- C use a torque wrench and tighten to the specified torque the tightening torque for r410a is the same as the conventional torque value for r22 be careful because if the torque is too weak it may lead to a gas leak if it is too strong it may split the flare nut or make it impossible to remove the flare nut 52
- Makings and management 52
- Procedure and precautions for flare connection 52
- Storing and managing piping materials 52
- Types of piping and their storage the following is a general classification of the refrigerant pipe materials used for acs 52
- Inspecting gas leaks with a vacuum pump for new installations using new refrigerant piping 53
- Installation transferring servicing 53
- Ac units replacement using existing refrigerant piping 54
- Recharging refrigerant during servicing 54
- Refrigerant compatibility using r410a refrigerant in r22 acs and vice versa 54
- Transferring using new refrigerant piping 54
- Brazing 56
- Servicing tips 56
- Carry out test running to confirm that no abnormality occurs after the installation then explain to user the operation care and maintenance as stated in instructions please remind the customer to keep the operating instructions for future reference 57
- Electrical work must be installed by a licensed electrician be sure to use the correct rating of the power plug and main circuit for the model to be installed 57
- Installation instructions 57
- Read the following safety precautions carefully before installation 57
- Safety precautions 57
- The caution items stated here must be followed because these important contents are related to safety the meaning of each indication used is as below incorrect installation due to ignoring of the instruction will cause harm or damage and the seriousness is classified by the following indications 57
- The items to be followed are classified by the symbols 57
- How to fix installation plate 60
- Indoor unit 60
- Indoor unit installation 60
- Select the best location refer to select the best location section 60
- To drill a hole in the wall and install a sleeve of piping 60
- Connect the cable to the indoor unit 62
- Connecting the piping 63
- Install the outdoor unit 63
- Outdoor unit 63
- Select the best location refer to select the best location section 63
- A evacuation of the equipment for europe oceania destination 64
- Connect the cable to the outdoor unit 65
- Pipe insulation 65
- A cooling 66
- B heating 66
- Caution 66
- During troubleshooting and servicing rated compressor operating frequency must be obtained in order to check the specification and technical data below are the methods used to obtain rated compressor operating specification 66
- Press the auto button continuously for 8 seconds or less than 11 seconds the air conditioner starts operation at heating rated frequency beep beep will be heard at the 8th second 66
- Rated frequency operation 66
- Servicing information 66
- Troubleshooting 66
- Breakdown self diagnosis function 68
- Button once next error code will be displayed press v button once previous error code will be displayed 68
- By pressing the tmer 68
- Carry on the measurements of pressure electric current and temperature fifteen minutes after an operation is started 68
- If check button is press again or without any operation for 30 seconds the diagnosis mode will turn off 68
- If error code displayed matches the error code saved in unit memory abnormality detected four beep sounds will be heard and power led will light on otherwise one beep sound is heard 68
- Once abnormality detected during operation the unit will immediately stop its operation timer led is blinking and maximum of three error codes abnormality will be saved in memory the abnormality of the operation can be identified through the below breakdown diagnosis method 68
- Press check button at remote controller continuously for more than five seconds to turn on the diagnosis mode h11 will be displayed at remote controller 68
- Relationship between the condition of the air conditioner and pressure and electric current 68
- Although operation forced to stop when abnormality detected emergency operation is possible for certain errors refer to error codes table by using remote controller or auto switch at indoor unit however the remote controller signal receiving sound is changed from one beep to four beep sounds 69
- Error codes table 69
- The memory data of error code is erased when the power supply is cut off or press the auto switch until beep sound heard following by pressing the reset button at remote controller 69
- Remote control 70
- A indoor control board removal procedures 71
- Disassembly of parts 71
- Remove the front grille 71
- Remove the indoor control board 71
- B electronic controller removal procedures 72
- Remove main electronic controller 72
- Remove power electronic controller 72
- C outdoor electronic controller removal procedure 74
- Remove the outdoor electronic controller 74
- Remove the top panel and front panel 74
- Exploded view 77
- All parts are supplied from maico malaysia vendor code 061 78
- O marked parts are recommended to be kept in stock 78
- Replacement parts list 78
- Exploded view 79
- All parts are supplied from maico malaysia vendor code 061 80
- O marked parts are recommended to be kept in stock 80
- Replacement parts list 80
- 10 9 8 81
- 2 3 4 5 81
- 5 4 3 2 1 81
- Cs e15ckp 81
- Electronic circuit diagram 81
- R46 270 r47 270 81
- R48 330 r18 1k 81
- R49 330 r50 330 r51 270 81
- Schematic diagram 1 3 81
- Cs e15ckp cu e15ckp5 82
- Receiver 82
- Schematic diagram 2 3 82
- Cs e15ckp cu e15ckp5 83
- Electronic control unit 83
- Schematic diagram 3 3 83
- Cs e15ckp cu e15ckp5 84
- Cu e15ckp5 84
- Schematic diagram 1 3 84
- A52d953aga17 85
- Cs e15ckp cu e15ckp5 85
- Schematic diagram 2 3 85
- Cs e15ckp cu e15ckp5 86
- Ic 3 an1393s 86
- Schematic diagram 3 3 86
Похожие устройства
- Клэр Радиус-01 Интер Паспорт
- Клэр Радиус-01 ФТ Паспорт
- Клэр Радиус-01 Интер СМ Паспорт
- Panasonic CS-F24DD2E5 / CU-B24DBE5 Сервис мануал
- Panasonic CS-F28DD2E5 / CU-B28DBE5 Сервис мануал
- Panasonic CS-F28DD2E5 / CU-B28DBE8 Сервис мануал
- Panasonic CS-F34DD2E5 / CU-B34DBE5 Сервис мануал
- Panasonic CS-F34DD2E5 / CU-B34DBE8 Сервис мануал
- Panasonic CS-F43DD2E5 / CU-B43DBE8 Сервис мануал
- Panasonic CS-F50DD2E5 / CU-B50DBE8 Сервис мануал
- Panasonic CS-V28EKE / CU-V28EKE Сервис мануал
- Panasonic CS-A12ATP5 / CU-A12ATP5 Сервис мануал
- Panasonic CS-A18ATP5 / CU-A18ATPT5 Сервис мануал
- Panasonic CS-A24ATP5 / CU-A24ATPT5 Сервис мануал
- Panasonic CS-F24DD3E5 / CU-B24DBE5 Сервис мануал
- Panasonic CS-F28DD3E5 / CU-B28DBE5 Сервис мануал
- Panasonic CS-F28DD3E5 / CU-B28DBE8 Сервис мануал
- Panasonic CS-F34DD3E5 / CU-B34DBE5 Сервис мануал
- Panasonic CS-F34DD3E5 / CU-B34DBE8 Сервис мануал
- Panasonic CS-F43DD3E5 / CU-B43DBE8 Сервис мануал
