NO CODE DESC_SPEC PARA1 PARA2 LOCATION BLOCK DB93-10859A DB93-10859D
1 DB41-00971A PCB˗90*120mm,FR-1 PCB MAIN PCB PCB 1 1
2 3711-004379 BOX,4P,1R,2mm,STRAIGHT,SN,WHT SMW200-04P CONNECT CN43 1 1
3 2007-001068 6.8Kohm,1%,1/10W,TP,1608 6.8Kohm 1608 R-CHIP R401 1 1
4 2007-001068 6.8Kohm,1%,1/10W,TP,1608 6.8Kohm 1608 R-CHIP R402 1 1
5 2007-000076 330ohm,5%,1/10W,TP,1608 330ohm 1608 R-CHIP R403 1 1
6 2007-000076 330ohm,5%,1/10W,TP,1608 330ohm 1608 R-CHIP R404 1 1
7 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CHIP C401 1 1
8 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CHIP C402 1 1
9 1103-001431 AT24C08BN,8Kbit,1Kx8,SOP,8P,4.9x3.9mm,1.8/5.5,-40to+85C,18uA,TP AT24C08BN,8Kbit IC-EEPROM IC03 1 1
10 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R502 1 1
11 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R503 1 1
12 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R504 1 1
13 3002-001129 BUZZER-PIEZO;85DB,-,-,2KHZ,- CBE2220BPC / TDP-2020P BUZZER BZ61 1 1
14 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 330-J 1608 R-CHIP R601 1 1
15 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 330-J 1608 R-CHIP R602 1 1
16 0501-000534 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SOT-23,TP,180- 2SC2412K TR-SMALL SIGNAL Q601 1 1
17 3711-000879 SMW250-03 AC REPLY TERMINAL
CONNECT CN44 1 1
18 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1K-J R-CHIP R405 1 1
19 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 6.8K-J R-CHIP R406 1 1
20 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1K-J R-CHIP R407 1 1
21 0501-000534 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SOT-23,TP,180- 2SC2412K TR-SMALL SIGNAL Q401 1 1
22 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 10nF C-CHIP C403 1 1
23 0506-000175 TR-ARRAY;2003,NPN,7,1W,SOP-16,ST,1000 ULN2003D013TR TR-ARRAY IC05 1 1
24 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608,- 100nF,1608 C-CHIP C504 1 1
25 3711-004484 SMW200-05 STEP MOTOR CONNECTOR CONNECT CN61 1 1
26 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C201 1 1
27 0604-001172 PHOTO-COUPLER TLP181-GRH-TPL PHOTO-COUPLER PC02 1 1
28 2007-000084 R-CHIP 4.7K-J R-CHIP R205 1 1
29 2007-000078 R-CHIP 1Kohm,5% R-CHIP R206 1 1
30 3711-007067 SMW200-06 DOWNLOAD CONNECT CONNECT CN31 1 1
31 2203-005249 100nF,10%,50V,X7R,TP,1608 100nF,1608 C-CHIP C301 1 1
32 2203-005249 100nF,10%,50V,X7R,TP,1608 100nF,1608 C-CHIP C303 1 1
33 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R301 1 1
34 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R302 1 1
35 2007-000078 1Kohm,5% 1.0Kohm 1608 R-CHIP R304 1 1
36 2007-001318 R-CHIP;1Kohm,5%,1/4W,TP,3216 1.0Kohm 3216 R-CHIP R305 1 1
37 2007-000090 10Kohm,5%,1/10W,TP,1608 10Kohm 1608 R-CHIP R306 1 1
38 1203-006245 IC-VOL. DETECTOR KIA7033AT,TSM,3P
RESET IC IC06 1 1
39 2007-000078 1Kohm,5% 1.0Kohm 1608 R-CHIP R303 1 1
40 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CHIP C302 1 1
41 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 1Mohm,1608 R-CHIP R501 1 1
42 2802-001198 RESONATOR-CERAMIC;10MHZ,0.5%,BK,8X3X5.5MM 10MHZ RESONATOR-CERAMIC X501 1 1
43 DB91-01167A MICOM ASSY-MIC IC04 1 1
44 DB09-00588A IC MICOM S3F84VBXZZ-QT8B IC MICOM IC04-1 1 1
45 2203-000257 10nF,10%,50V,X7R,TP,1608 10nF,1608 C-CHIP C501 1 1
46 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CHIP C502 1 1
47 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CHIP C503 1 1
48 3501-001268 RELAY-POWER;12V,0.9W,25000mA,SPST,20mS,10mS
RELAY RY71 COMP 1 1
49 3711-000262 AC MOTOR CONNECT YW396-05AV CONNECT CN72 1 1
50 3502-000115 SSR AQG22212 SSR SS71 1 1
51 2001-000429 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm R-CARBON R901 1 1
52 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 47Kohm 1608 R-CHIP R902 1 1
53 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,- 1nF 1608 C-CHIP C901 1 1
54 1405-000160 VARISTOR;680V,4500A,17.5x6.5mm,TP,INR14D681KORSY INR14D681 / GNR14D681K,7.5mm VARISTOR VA71 1 1
55 DB67-00942A VARISTOR CAP PROTECT VARISTOR-CAP VA71-CAP 1 1
56 2301-002032 100nF,10%,275V 12.5X6X12.0 C-FILM XC72 1 1
57 DB27-00017A COIL CHOKE;JL-004-15mH JL-004-15mH COIL CHOKE FT71 1 1
58 3601-001209 FUSE-RADIAL LEAD;250V,1A,TIME-LAG,-,8.5x8mm LT-5-010-H FUSE-RADIAL LEAD F702 1 1
59 0402-001298 DIODE-BRIDGE;DF06S,600V,1A,SMD-4,TP DF06S DIODE-BRIDGE BD71 1 1
60 2003-000706 47Kohm,5%,2W,AA,TP,4.3x12mm R-METAL OXIDE(S) R105 1 1
61 2201-000983 C-CERAMIC,DISC
1NF,10%ˈ2KV C-CERAMIC C103 1 1
62 2007-000781 R-CHIP;33ohm,5%,1/8W,TP,2012 33-J R-CHIP
R106
11
63 0402-000137 DIODE-RECTIFIER;1N4007,1KV,1A,DO-41,TP 1N4007 DIODE-RECTIFIER D101 1 1
64 0402-001427 DIODE-RECTIFIER;ES1D,200V,1A,DO-214AC,TP ES1D 200V/1A D102 1 1
65 0402-001192 ES2D,200V,2A,SMB,TP 200V,2A D103 1 1
66 2201-000987 C-CERAMIC,DISC 2.2nF 400V C107 1 1
67 2201-000987 C-CERAMIC,DISC 2.2nF 400V C108 1 1
68 2401-001998 C-AL 1000uF,20%,25V,GP,TP,10x20,5mm C-AL C109 1 1
69 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C110 1 1
70 2401-000807 C-AL 220uF,20%,16V,GP,TP,8x11.5,5 C-AL C111 1 1
71 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C112 1 1
72 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C113 1 1
73 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C104 1 1
74 2401-002619 C-AL 47uF,20%,25V,GP,TP,5x11,5 C-AL C105 1 1
75 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 C-AL C106 1 1
76 2007-001074 6.8ohm,5%,1/8W,TP,2012 6.8ohmˈ2012 R-CHIP R107 1 1
77 2007-000074 100ohm,5%,1/10W,TP,1608 100ohmˈ1608 R-CHIP R110 1 1
78 2007-000081 2.7Kohm,5%,1/10W,TP,1608 2.7Kohmˈ1608 R111 1 1
79 2007-000077 R-CHIP 470-J 1/10W,1608 R112 1 1
80 1203-006089 IC-PWM CONTROLLER TOP253PN,DIP,7P,6.35x9.57mm,PLAS IC01 1 1
81 DB26-00115A TRANS ST11 1 1
82 0604-001002 PHOTO-COUPLER;TR,100-600%,200mW,SOP-4,TP TLP181-GB PC01 1 1
83 0504-001064 TR-DIGITAL DTC114EKA 200mW Q101 1 1
84 0403-001285 DIODE-ZENER BZX84-C11 11V/350mW ZD01 1 1
85 0403-000258 DIODE-ZENER BZX84C5V6 5.6V/225mW ZD02 1 1
86 DB93-10917A 2 PIN HARNESS CN11 1 1
87 3711-000260 AC MOTOR CONNECT YW396-05AV BLU CN71 1 1
88 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216
JUMPER WIRE, R-CHIP J2 1 1
89 3812-001283 JUMPER WIRE JUMPER WIRE J3 1 1
90 3812-001283 JUMPER WIRE JUMPER WIRE J4 1 1
91 3812-001283 JUMPER WIRE JUMPER WIRE J5 1 1
92 3812-001283 JUMPER WIRE JUMPER WIRE J6 1 1
93 3812-001283 JUMPER WIRE JUMPER WIRE J7 1 1
94 3812-001283 JUMPER WIRE JUMPER WIRE J8 1 1
95 3812-001283 JUMPER WIRE JUMPER WIRE J9 1 1
96 3812-001283 JUMPER WIRE JUMPER WIRE J10 1 1
97 3812-001283 JUMPER WIRE JUMPER WIRE J11 1 1
98 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216
JUMPER WIRE, R-CHIP J12 1 1
99 3812-001283 JUMPER WIRE JUMPER WIRE J13 1 1
100 3812-001283 JUMPER WIRE JUMPER WIRE J14 1 1
101 3812-001283 JUMPER WIRE JUMPER WIRE J15 1 1
102 3812-001283 JUMPER WIRE JUMPER WIRE J16 1 1
103 3812-001283 JUMPER WIRE JUMPER WIRE J17 1 1
104 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216
JUMPER WIRE, R-CHIP J18 1 1
105 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216
JUMPER WIRE, R-CHIP J19 1 1
106 3812-001283 JUMPER WIRE JUMPER WIRE J20 1 1
107 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216
JUMPER WIRE, R-CHIP J21 1 1
108 3812-001283 JUMPER WIRE JUMPER WIRE J22 1 1
109 3812-001283 JUMPER WIRE JUMPER WIRE J23 1 1
110 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216
JUMPER WIRE, R-CHIP J24 1 1
111 3812-001283 JUMPER WIRE JUMPER WIRE J25 1 1
112 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216
JUMPER WIRE, R-CHIP J26 1 1
113 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216
JUMPER WIRE, R-CHIP J27 1 1
114 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216
JUMPER WIRE, R-CHIP J28 1 1
115 3812-001283 JUMPER WIRE JUMPER WIRE J29 1 1
116 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216
JUMPER WIRE, R-CHIP J30 1 1
117 3812-001283 JUMPER WIRE JUMPER WIRE J31 1 1
118 3812-001283 JUMPER WIRE JUMPER WIRE J32 1 1
119 3812-001283 JUMPER WIRE JUMPER WIRE J33 1 1
120 3812-001283 JUMPER WIRE JUMPER WIRE J34 1 1
121 6042-000001 EYELET Φ3.0 EYELET RY71-1 1 1
122 6042-000001 EYELET Φ3.0 EYELET RY71-2 1 1
123 6042-000001 EYELET Φ3.0 EYELET RY71-3 1 1
124 6042-000001 EYELET Φ3.0 EYELET RY71-4 1 1
125 6042-000001 EYELET Φ3.0 EYELET CN71-1 1 1
126 6042-000001 EYELET Φ3.0 EYELET CN71-3 1 1
127 6042-000001 EYELET Φ3.0 EYELET CN72-1 1 1
128 6042-000001 EYELET Φ3.0 EYELET CN72-3 1 1
129 6042-000002 EYELET Φ2.2 EYELET F701 1 1
130 6042-000002 EYELET Φ2.2 EYELET F701 1 1
131 6042-000002 EYELET Φ2.2 EYELET CR71 1 1
132 6042-000002 EYELET Φ2.2 EYELET CR71 1 1
133 6042-000002 EYELET Φ2.2 EYELET C101 1 1
134 6042-000002 EYELET Φ2.2 EYELET C101 1 1
135 6042-000002 EYELET Φ2.2 EYELET C102 1 1
136 6042-000002 EYELET Φ2.2 EYELET C102 1 1
137 1203-002560 IC-POSI.FIXED REG. NJM7805,TO-220F,3P,-,PLASTIC,4. 1.5A IC02 0 0
138 1203-000274 IC-POSI.FIXED REG. 7805,TO-220,3P,-,PLASTIC,4.8/5 1.0A IC02 1 1
139 1203-000429 IC-POSI.FIXED REG. KA78L05AZTA 0.1A IC02-1 0 0
140 3711-000941 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,STRAIGHT,SN SMW250-04 YEL CN81 SPI 1 1
141 2002-001104 R-COMPOSITION 12M-J 1/2W R108 1 1
142 2002-001104 R-COMPOSITION 12M-J 1/2W R109 1 1
143 3711-004349 HEADER-BOARD TO CABLE;BOX,3P,1R,2mm,STRAIGHT,SN,NT SMW200-03 NTR CN42 1 1
144 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 330-J 1/10W,1608 R408 1 1
145 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608,- 100nF 50V,1608 C404 0 0
146 1404-001274 THERMISTOR-NTC NTC-22D-7(F) 1.4A/3100K NTC 0 0
147 3812-001283 JUMPER WIRE JUMP NTC 1 1
148 2301-002032 100nF,10%,275V 12.5X6X12.0 XC71 EMI 1 1
149 3501-001154 RELAY-MINIATURE;12Vdc,200mW,3000mA,1FormA,10mS,10m PCJ-112D3MH,501X 12Vdc,3A RY74 0 0
150 3812-001283 JUMPER WIRE JUMP RY74 1 1
151 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP D702 0 0
152 0504-001064 TR-DIGITAL DTC114EKA 200mW Q702 0 0
153 3711-003843 SMW200-08 DISPLAY CONNECT WHT CN91(8PIN) 0 0
154 3711-004712 SMW200-09 DISPLAY CONNECT WHT CN91(9PIN) 1 1
155 3502-000115 SSR AQG22212 12Vdc/2A SS72 SSR 0 0
156 2007-000481 1Mohm,5%,1/4W,TP,3216 1Mohm,3216 R-CHIP R101 1 1
157 2007-000481 1Mohm,5%,1/4W,TP,3216 1Mohm,3216 R-CHIP R102 1 1
158 2007-000481 1Mohm,5%,1/4W,TP,3216 1Mohm,3216 R-CHIP R103 1 1
159
2007-007385 1.2Mohm,1%,1/4W,TP,3216 1.2Mohm,3216
R-CHIP R113
11
160 2007-000033 0ohm,5%,1/4W,TP,3216 0ohm,3216 R-CHIP R104 0 0
161 3601-001288 250V,2.5A,TIME-LAG,CERAMIC-TUBE,5.25X22.5MM 250V,2.5A F701 1 1
162 3601-001336 250V,3.15A,TIME-LAG,CERAMIC,5.25X22.5MM 250V,3.15A F701 0 0
163 2401-003763 33uF,20%,450V,GP,TP,16x31.5mm,5mm C102 1 1
164 2401-003763 33uF,20%,450V,GP,TP,16x31.5mm,5mm C101 1 1
165 2401-004219 15uF,20%,500V,TP,12.5x20mm,5mm C101-1 0 0
166 2001-000436 R-CARBON 0ohm,5%,1/4W,AA,TP,2.4x6.4mm J1 0 0
167 3501-001154 RELAY-MINIATURE;12Vdc,200mW,3000mA,1FormA,10mS,10m PCJ-112D3MH,501X 12Vdc,3A RY73 1 0
168 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP D601 1 0
169 0504-001064 TR-DIGITAL DTC114EKA Q602 1 0
170 3501-001154 RELAY-MINIATURE;12Vdc,200mW,3000mA,1FormA,10mS,10m PCJ-112D3MH,501X 12Vdc,3A RY72 1 0
171 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP D701 1 0
172 0504-001064 TR-DIGITAL DTC114EKA Q701 1 0
173 2301-001915 C-FILM,LEAD-PPF 1.2uF 450V CR71 1 1
174 2301-001916 C-FILM,LEAD-PPF 2.0uF 450V CR71 0 0
175 2301-001917 C-FILM,LEAD-PPF 4.0uF 450V CR71 0 0
176 2003-001093 R-METAL OXIDE(S) 12Kohm,5%,2W,AA,TP,4x12mm R201 0 0
177 2003-000487 R-METAL OXIDE(S) 12Kohm,5%,2W,AF,TP,3.9x10mm R202 0 0
178 2003-002409 R-METAL OXIDE(S) 24Kohm,5%,2W,AA,TP 4x11mm R201 1 1
179 2003-000598 R-METAL OXIDE(S) 24Kohm,5%,2W,AA,TP 4x12mm R202 1 1
4-WAY
OUT FAN
FUSE
NTC
POWER SAVE
DISPLAY
7805
GND GAN
SENSOR
AC MOTOR
DISPLAY
SMPS
JUMP WIRE
EYELET
AC MOTOR
REPLY
2003 DRIVE
DOWNLOAD
RESET
TEMPERATU
R
E
SENSOR
EEPROM
BUZZER

Содержание

Похожие устройства

Скачать
