NO CODE DESC_SPEC PARA1 PARA2 LOCATION BLOCK DB93-10860A DB93-10860B

1 DB93-11027A BLDC-PROTECTION BLDC-PROTECTION 1 1

2 DB41-00973A FR-1 PCB PCB BOARD 1 1

3 3711-004379 BOX,4P,1R,2mm,STRAIGHT,SN,WHT SMW200-04P WHT CN43 1 1

4 2007-001068 6.8Kohm,1%,1/10W,TP,1608 6.8Kohm 1608 R-CHIP R401 1 1

5 2007-001068 6.8Kohm,1%,1/10W,TP,1608 6.8Kohm 1608 R-CHIP R402 1 1

6 2007-000076 330ohm,5%,1/10W,TP,1608 330ohm 1608 R-CHIP R403 1 1

7 2007-000076 330ohm,5%,1/10W,TP,1608 330ohm 1608 R-CHIP R404 1 1

8 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C401 1 1

9 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C402 1 1

10 1103-001431 AT24C08BN,8Kbit,1Kx8,SOP,8P,4.9x3.9mm,1.8/5.5,-40to+85C,18uA,TP AT24C08BN,8Kbit IC03 1 1

11 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R502 1 1

12 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R503 1 1

13 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R504 1 1

14 3002-001129 BUZZER-PIEZO;85DB,-,-,2KHZ,- CBE2220BPC / TDP-2020P 85dB BZ61 1 1

15 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 330-J 1608 R-CHIP R601 1 1

16 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 330-J 1608 R-CHIP R602 1 1

17 0501-000534 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SOT-23,TP,180- 2SC2412K 200mW Q601 1 1

18 2007-000090 10Kohm,5%,1/10W,TP,1608 10Kohm 1608 R-CHIP R701 1 1

19 2007-000090 10Kohm,5%,1/10W,TP,1608 10Kohm 1608 R-CHIP R702 1 1

20 2007-001093 620ohm,5%,1/10W,TP,1608 620ohm 1608 R-CHIP R703 1 1

21 2007-000090 10Kohm,5%,1/10W,TP,1608 10Kohm 1608 R-CHIP R704 1 1

22 2007-000090 10Kohm,5%,1/10W,TP,1608 10Kohm 1608 R-CHIP R705 1 1

23 2007-000078 1K-Jˈ1/10W,1608 1Kohm 1608 R-CHIP R706 1 1

24 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R707 1 1

25 2007-001179 8.2Kohm,5%,1/10W,TP,1608 8.2Kohm 1608 R-CHIP R708 1 1

26 2401-002300 47uF,20%,50V,GP,TP,6.3x11,5mm 47uF,50V C-AL C701 1 1

27 2203-005249 100nF,10%,50V,X7R,TP,1608 100nF,1608 C-CER,CHIP C702 1 1

28 2401-002300 47uF,20%,50V,GP,TP,6.3x11,5mm 47uF,50V C-AL C703 1 1

29 2203-005249 100nF,10%,50V,X7R,TP,1608 100nF,1608 C-CER,CHIP C704 1 1

30 2203-000257 10nF,10%,50V,X7R,TP,1608 10nF,1608 C-CER,CHIP C705 1 1

31 2401-000027 4.7uF,20%,50V,GP,TP,5x11,5 4.7uF,50V C-AL C706 1 1

32 2203-005249 100nF,10%,50V,X7R,TP,1608 100nF,1608 C-CER,CHIP C707 1 1

33 2203-006104 1000nF,10%,50V,X7R,3225 C-CER,CHIP C708 1 1

34 0501-000294 TR-SMALL SIGNAL KSA708-Y,PNP,800mW,TO-92,TP,12 TR-SMALL SIGNAL Q701 1 1

35 0604-001002 TR,100-600%,200mW,SOP-4,TP PHOTO-COUPLER PHOTO-COUPLER PC03 1 1

36 0604-001002 TR,100-600%,200mW,SOP-4,TP PHOTO-COUPLER PHOTO-COUPLER PC04 1 1

37 0604-001002 TR,100-600%,200mW,SOP-4,TP PHOTO-COUPLER PHOTO-COUPLER PC05 1 1

38 3711-000296 HEADER-BOARD TO CABLE 1WALL,6P,1R,3.96MM,STRAIGHT,SN,

CONNECT CN72 1 1

39 0402-000137 1N4007,1000V,1A,DO-41,TP DIODE-RECTIFIER DIODE-RECTIFIER D701 1 1

40 1203-001238 78L15,TO-92,3P,-,PLASTIC IC-POSI.ADJUST REG. IC-POSI.ADJUST REG IC07 1 1

41 0506-000175 TR-ARRAY;2003,NPN,7,1W,SOP-16,ST,1000 ULN2003D013TR 1W IC08 1 1

42 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608,- 100nF,1608 C-CER,CHIP C506 1 1

43 0506-000175 TR-ARRAY;2003,NPN,7,1W,SOP-16,ST,1000 ULN2003D013TR 1W IC05 1 1

44 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608,- 100nF,1608 C-CER,CHIP C504 1 1

45 3711-004484 CONNECTOR-HEADER;BOX,5P,1R,2mm,STRAIGHT,SN SMW200-05 NTR CN61 1 1

46 3711-007067 BOX,6P,1R,2mm,STRAIGHT,SN,BL HEADER-BOARD TO CABLE BLACK CN31 1 1

47 2203-005249 100nF,10%,50V,X7R,TP,1608 100nF,1608 C-CER,CHIP C301 1 1

48 2203-005249 100nF,10%,50V,X7R,TP,1608 100nF,1608 C-CER,CHIP C303 1 1

49 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R301 1 1

50 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R302 1 1

51 2007-000078 1Kohm,5% 1.0Kohm 1608 R-CHIP R304 1 1

52 2007-000078 1Kohm,5% 1.0Kohm 1608 R-CHIP R305 1 1

53 2007-000090 10Kohm,5%,1/10W,TP,1608 10Kohm 1608 R-CHIP R306 1 1

54 1203-006245 IC-VOL. DETECTOR KIA7033AT,TSM,3P IC09 1 1

55 2007-000043 1Kohm,1% 1.0Kohm 1608 R-CHIP R303 1 1

56 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C302 1 1

57 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 1Mohm,1608 R-CHIP R501 1 1

58 2802-001198 RESONATOR-CERAMIC;10MHZ,0.5%,BK,8X3X5.5MM 10MHZ X501 1 1

59 DB91-01166A MICOM IC04 1 1

60 DB09-00588A IC MICOM S3F84VBXZZ-QT8B IC04-1 1 1

61 2203-000257 10nF,10%,50V,X7R,TP,1608 10nF,1608 C-CER,CHIP C501 1 1

62 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C502 1 1

63 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C503 1 1

64 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C201 1 1

65 0604-001172 PHOTO-COUPLER TLP181-GRH-TPL 100-300% PC02 1 1

66 2007-000084 4.7Kohm,5%,1/10W,TP,1608 4.7Kohm 1608 R-CHIP R205 1 1

67 2007-000078 1Kohm,5% 1.0Kohm 1608 R-CHIP R206 1 1

68 3711-000015 CONNECT 2PIN CONNECT 2PIN CONNECT CN74 0 0

69 DB93-07163N WIRE TO T/B

AWG#18 BRN WIRE L 0 0

70 3501-001268 RELAY-POWER;12V,0.9W,25000mA,SPST,20mS,10mS RY71 1 1

71 2007-000078 1Kohm,5% 1.0Kohm 1608 R-CHIP R901 1 1

72 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 47Kohm 1608 R-CHIP R902 1 1

73 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,- 1nF 1608 C-CER,CHIP C901 1 1

74 1405-000160 VARISTOR;680V,4500A,17.5x6.5mm,TP,INR14D681KORSY INR14D681 / GNR14D681K,7.5mm 680V,4500A VA71 1 1

75 DB67-00942A VARISTOR CAP PROTECT VA71-CAP 1 1

76 2301-001220 100nF,10%,275V XC72 1 1

77 2301-001220

100 nF,10%,275V XC71 1 1

78 DB27-00017A COIL CHOKE;JL-004-15mH JL-004-15mH * / 15mH FT71 1 1

79 3601-001209 FUSE-RADIAL LEAD;250V,1A,TIME-LAG,-,8.5x8mm LT-5-010-H 250V,1A F702 1 1

80 0402-001227 D3SBA60 600V/2.3A BD71 1 1

81 1404-001274 THERMISTOR-NTC NTC-22D-7(F) 1.4A/3100K NTC 1 1

82 2401-004393 100uF,20%,500V,-,BK,25.4x30mm,10100uF,20%,500V 100uF,500V C101 1 1

83 2003-000706 47Kohm,5%,2W,AA,TP,4.3x12mm R105 1 1

84 2201-000983 C-CERAMIC,DISC 1NF,10% 2KV C103 1 1

85 2007-000781 R-CHIP;33ohm,5%,1/8W,TP,2012 33-J 1/8W,2012

R106

86 0402-000137 DIODE-RECTIFIER;1N4007,1KV,1A,DO-41,TP 1N4007 1000V/1A D101 1 1

87 0402-001427 DIODE-RECTIFIER;ES1D,200V,1A,DO-214AC,TP ES1D 200V/1A D102 1 1

88 0402-001192 ES2D,200V,2A,SMB,TP 200V,2A D103 1 1

89 2201-000987 C-CERAMIC,DISC 2.2nF 400V C107 1 1

90 2201-000987 C-CERAMIC,DISC 2.2nF 400V C108 1 1

91 2401-001998 C-AL 1000uF,20%,25V,GP,TP,10x20,5mm C109 1 1

92 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C110 1 1

93 2401-000807 C-AL 220uF,20%,16V,GP,TP,8x11.5,5 C111 1 1

94 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C112 1 1

95 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C113 1 1

96 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C104 1 1

97 2401-002619 C-AL C105 1 1

98 2401-000480 C-AL C106 1 1

99 2007-001074 6.8ohm,5%,1/8W,TP,2012 6.8ohmˈ2012 R-CHIP R107 1 1

100 2007-000074 100ohm,5%,1/10W,TP,1608 100ohmˈ1608 R-CHIP R110 1 1

101 2007-000081 2.7Kohm,5%,1/10W,TP,1608 R111 1 1

102 2007-000077 R-CHIP 470-J 1/10W,1608 R116 1 1

103 1203-006089 IC-PWM CONTROLLER TOP253PN,DIP,7P,6.35x9.57mm,PLAS IC01 1 1

104 DB26-00116A TRANS ST11 1 1

105 0604-001002 PHOTO-COUPLER;TR,100-600%,200mW,SOP-4,TP TLP181-GB PC01 1 1

106 0504-001064 TR-DIGITAL DTC114EKA 200mW Q101 1 1

107 0403-001285 DIODE-ZENER BZX84-C11 11V/350mW ZD01 1 1

108 0403-000258 DIODE-ZENER BZX84C5V6 5.6V/225mW ZD02 1 1

109 DB93-10917A 2 PIN HARNESS CN11 1 1

110 3711-000260 HEADER-BOARD TO CABLE 1WALL,3P,1R,7.92mm,STRAIGHT, CN71 1 1

111 3812-001283 JUMPER WIRE J1 1 1

112 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J2 1 1

113 3812-001283 JUMPER WIRE J3 1 1

114 3812-001283 JUMPER WIRE J4 1 1

115 3812-001283 JUMPER WIRE J5 1 1

116 3812-001283 JUMPER WIRE J6 1 1

117 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J7 1 1

118 3812-001283 JUMPER WIRE J8 1 1

119 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J9 1 1

120 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J10 1 1

121 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J11 1 1

122 3812-001283 JUMPER WIRE J12 1 1

123 3812-001283 JUMPER WIRE J13 1 1

124 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J14 1 1

125 3812-001283 JUMPER WIRE J15 1 1

126 3812-001283 JUMPER WIRE J16 1 1

127 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J17 1 1

128 3812-001283 JUMPER WIRE J18 1 1

129 3812-001283 JUMPER WIRE J19 1 1

130 3812-001283 JUMPER WIRE J20 1 1

131 3812-001283 JUMPER WIRE J21 1 1

132 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J22 1 1

133 3812-001283 JUMPER WIRE J23 1 1

134 3812-001283 JUMPER WIRE J24 1 1

135 3812-001283 JUMPER WIRE J25 1 1

136 3812-001283 JUMPER WIRE J26 1 1

137 3812-001283 JUMPER WIRE J27 1 1

138 3812-001283 JUMPER WIRE J28 1 1

139 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J29 1 1

140 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J30 1 1

141 3812-001283 JUMPER WIRE J31 1 1

142 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J32 1 1

143 3812-001283 JUMPER WIRE J33 1 1

144 3812-001283 JUMPER WIRE J34 0 0

145 3812-001283 JUMPER WIRE J35 1 1

146 3812-001283 JUMPER WIRE J36 1 1

147 3812-001283 JUMPER WIRE J37 1 1

148 3812-001283 JUMPER WIRE J38 1 1

149 3812-001283 JUMPER WIRE J39 1 1

150 3812-001283 JUMPER WIRE

J40 1 1

151 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J41 1 1

152 3812-001283 JUMPER WIRE J42 1 1

153 3812-001283 JUMPER WIRE J43 1 1

154 3812-001283 JUMPER WIRE J44 1 1

155 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J45 1 1

156 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J46 1 1

157 3812-001283 JUMPER WIRE J47 1 1

158 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J48 1 1

159 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J49 1 1

160 3812-001283 JUMPER WIRE J50 1 1

161 2007-000033 R-CHIP 0ohm,5%,1/4W,TP,3216 J51 1 1

162 6042-000001 EYELET Φ3.0 RY71-1 1 1

163 6042-000001 EYELET Φ3.0 RY71-2 1 1

164 6042-000001 EYELET Φ3.0 RY71-3 1 1

165 6042-000001 EYELET Φ3.0 RY71-4 1 1

166 6042-000001 EYELET Φ3.0 CN71-1 1 1

167 6042-000001 EYELET Φ3.0 CN71-3 1 1

168 6042-000001 EYELET Φ3.0 C101-1 1 1

169 6042-000001 EYELET Φ3.0 C101-2 1 1

170 6042-000002 EYELET Φ2.2 F701 1 1

171 6042-000002 EYELET Φ2.2 F701 1 1

172 1203-002560 IC-POSI.FIXED REG. NJM7805,TO-220F,3P,-,PLASTIC,4. 1.5A IC02 0 0

173 1203-000274 IC-POSI.FIXED REG. 7805,TO-220,3P,-,PLASTIC,4.8/5 1.0A IC02 1 1

174 1203-000429 IC-POSI.FIXED REG. KA78L05AZTA 0.1A IC02-1 0 0

175 2007-000481 1Mohm,5%,1/4W,TP,3216 1Mohm,3216 R-CHIP R101 1 1

176 2007-000481 1Mohm,5%,1/4W,TP,3216 1Mohm,3216 R-CHIP R102 1 1

177 2007-000481 1Mohm,5%,1/4W,TP,3216 1Mohm,3216 R-CHIP R103 1 1

178

2007-007385 1.2Mohm,1%,1/4W,TP,3216 1.2Mohm,3216

R-CHIP R117

179 2007-000033 0ohm,5%,1/4W,TP,3216 0ohm,3216 R-CHIP R104 0 0

180 3711-000941 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,STRAIGHT,SN SMW250-04 YEL CN81 MPI 1 1

181 2002-001104 R-COMPOSITION 12M-J 1/2W R108 1 1

182 2002-001104 R-COMPOSITION 12M-J 1/2W R109 1 1

183 3711-004349 HEADER-BOARD TO CABLE;BOX,3P,1R,2mm,STRAIGHT,SN,NT CN42 1 1

184 2007-000076 330ohm,5%,1/10W,TP,1608 330ohm 1608 R-CHIP R408 1 1

185 2203-005249 100nF,10%,50V,X7R,TP,100nF 100nF 1608 C-CER,CHIP C404 0 0

186 3711-003843 HEADER-BOARD TO CABLE BOX,8P,1R,2mm,STRAIGHT,SN,WHT 8P

CN91(8PIN)

187 3711-004712 CONNECTOR-HEADER;BOX,9P,1R,2MM,STRAIGHT,SN,NTR SMW200-09 9P

CN91(9PIN)

188 3501-001154 RELAY-MINIATURE;12Vdc,200mW,3000mA,1FormA,10mS,10m PCJ-112D3MH,501X 12Vdc/3A RY74 0 0

189 3812-001283 JUMPER WIRE JP 74 1 1

190 0504-001064 TR-DIGITAL;DTC114EKA,NPN,200mW,10K/10K,SOT-23,TP DTC114EKA 200mW Q702 0 0

191 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP D702 0 0

192 3502-000115 SSR AQG22212 12Vdc/2A SS72 SSR 0 0

193 2007-000924 R-CHIP 470Kohm,1%,1/4W,TP,3216 R-CHIP R112 1 1

194 2007-000924 R-CHIP 470Kohm,1%,1/4W,TP,3216 R-CHIP R113 1 1

195 2007-000924 R-CHIP 470Kohm,1%,1/4W,TP,3216 R-CHIP R114 1 1

196 2007-000385 R-CHIP 14.3Kohm,1%,1/4W,TP,3216 R-CHIP R115 1 1

197 3601-001288 250V,2.5A,TIME-LAG,CERAMIC-TUBE,5.25X22.5MM 250V,2.5A 18K USE F701 0 0

198 3601-001336 250V,3.15A,TIME-LAG,CERAMIC,5.25X22.5MM 250V,3.15A 24K USE F701 1 1

199 3501-001154 RELAY-MINIATURE;12Vdc,200mW,3000mA,1FormA,10mS,10m PCJ-112D3MH,501X 12Vdc,3A RY72 OUT FAN 1 0

200 3501-001154 RELAY-MINIATURE;12Vdc,200mW,3000mA,1FormA,10mS,10m PCJ-112D3MH,501X 12Vdc,3A RY73 1 0

201 0504-001064 TR-DIGITAL DTC114EKA 200mW Q703 1 0

202 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-323,TP D703 1 0

203 2003-001093 R-METAL OXIDE(S) 12Kohm,5%,2W,AA,TP,4x12mm R201 0 0

204 2003-000487 R-METAL OXIDE(S) 12Kohm,5%,2W,AF,TP,3.9x10mm R202 0 0

205 2003-002409 R-METAL OXIDE(S) 24Kohm,5%,2W,AA,TP 4x11mm R201 1 1

206 2003-000598 R-METAL OXIDE(S) 24Kohm,5%,2W,AA,TP 4x12mm R202 1 1

POWER SENSOR

FUSE

4-WAY

DISPLAY

POWER SAVE

7805( NO OPTION)

AGND GAN

COMP

DISPLAY

SMPS

JUMP WIRE

EYELET

BLDC

DRIVE

DOWNLOAD

RESET

TEMPERATURE

SENSOR

EEPROM

BUZZER

Samsung AS18TUBAXXVN [61/72] 007385 1 mohm 1 1 4w tp 3216 1 mohm 3216 r chip r117

Содержание

Похожие устройства
