10
Designs and specifications are subject to change without notice.
Troubleshooting
Symptom Cause Correction
General
No power.
No sound.
The power cord is not plugged in.
Check whether electricity failed.
Check whether you select right function.
Plug in the power cord.
Check the condition by operating other
electronic devices.
Press FUNCTION and check the
selected function.
CD
The unit does not
start playback.
An unplayable disc is inserted.
The disc is dirty.
Insert a playable disc.
Clean the disc.
Remote control
The remote control
does not work
properly.
The remote control is not pointed at the
remote sensor of the unit.
The remote control is too far from the
unit.
There is an obstacle in the path of the
remote control and the unit.
The battery in the remote control is
exhausted.
Point the remote control at the remote
sensor of the unit.
Operate the remote control within about
16 ft (5 m).
Remove the obstacle.
Replace the battery with new one.
Radio
Radio stations can’t
be tuned in properly.
The antenna is positioned poorly.
The signal strength of the radio station
is too weak.
No stations have been preset or preset
stations have been cleared (when tuning
by scanning preset channels).
Attach an external aerial if necessary.
Tune to the station manually.
Preset some radio stations.
Specifications
General
Power supply Refer to the main label
Power consumption Refer to the main label
Net Weight 2.8 kg
External dimensions (WxHxD) 170 x 244 x 275 mm
Operating temperature 5
o
C to 35
o
C
Operating humidity 5% to 85 %
Tuner
FM Tuning Range 87.5 - 108.0 MHz or
87.50 - 108.00 MHz
AM Tuning Range (optional)
522 - 1620 kHz or 520 - 1710 kHz
Amplifier
Output Power 30 W + 30 W
T.H.D 0.50 %
Frequency Response 50 Hz - 20 KHz
Signal-to-noise ratio 70 dB
CD
Frequency response 100 Hz - 18 KHz
Signal-to-noise ratio 70 dB
Dynamic range 55 dB
Speakers (XAS64F)
Type 2 Way 2 Speaker
Impedance 6 Ω
Rated Input Power 30 W
Max. Input Power 60 W
Net Dimensions (WxHxD) 150 x 244 x 182 mm
Net Weight (1EA) 1.9 kg
USB
Version 1.1
BUS Power supply DC 5 V 500 mA
Notice (the date of the production of goods).
First figure ( of the left ) of series number means Year,
next 2 figures - Month of the production of this goods.
XA64-F0U-AUKRLL-ENG 11/16/09 10:45 AM Page 10
