STANDARD PARTS
2-7
5680 331178 (07- 09)
Fig. 3 - Brushes, Replacement, Model 900, 900 mm (36 in)
Ref. Part No. Serial Number Description Qty.
1 11773 (10000000- ) Brush- Disk Scr 18 D Assy Nylon 2
Y
2 14838 (10000000- ) Spring, Brush Retaining 1
Y
3 24299 (10000000- ) Bracket, Spring Retainer 1
Y
4 01684 (10000000- ) Washer, Flat, 0.25 Ss 1
Y
5 32746 (10000000- ) Screw, Pan, M6 X 1.0 X 35, Ss 3
1 11771 (10000000- ) Brush-DiskScr-18D-Assy-Poly 2
Y
2 14838 (10000000- ) Spring, Brush Retaining 1
Y
3 24299 (10000000- ) Bracket, Spring Retainer 1
Y
4 01684 (10000000- ) Washer, Flat, 0.25 Ss 1
Y
5 32746 (10000000- ) Screw, Pan, M6 X 1.0 X 35, Ss 3
1 11772 (10000000- ) Brush- Disk Scr- 18 D Assy Ab 2
Y
2 14838 (10000000- ) Spring, Brush Retaining 1
Y
3 24299 (10000000- ) Bracket, Spring Retainer 1
Y
4 01684 (10000000- ) Washer, Flat, 0.25 Ss 1
Y
5 32746 (10000000- ) Screw, Pan, M6 X 1.0 X 35, Ss 3
6 397918 (10000000- ) Driver Assy, Pad, 18d 2
Y
7 397978 (10000000- ) Disk, Pad Driver, W/ Face, 18d 1
Y
8 15539 (10000000- ) Adaptor, Brush 1
Y
9 14838 (10000000- ) Spring, Brush Retaining 1
Y
10 24299 (10000000- ) Bracket, Spring Retainer 1
Y
11 370095 (10000000- ) Device, Centering 1
Y
12 09198 (10000000- ) Screw, Pan, M4 X 0.7 X 35, S 3
Y
13 41579 (10000000- ) Washer, Flat, #8, Ss 3
Y
14 01684 (10000000- ) Washer, Flat, 0.25 Ss 1
Y
15 32746 (10000000- ) Screw, Pan, M6 X 1.0 X 35, Ss 3
16 11777 (10000000- ) Pad, Strip 18D Brown 2
16 370093 (10000000- ) Pad, Strip- Hd 18D Black 2
16 11778 (10000000- ) Pad, Scrub 18D Blue 2
16 11780 (10000000- ) Pad, Buff 18D Red 2
16 11781 (10000000- ) Pad, Polish 18D White 2
16 1051029 (10000000- ) Pad, Surf Prep, 18.0d [Mar,1pick =1pad] 2
17 222310 (10000000- ) Brush, Scb, 36l, 18 Sr, Pyp Grout, Spl 2
17 374043 (10000000- ) Brush, Scb, 36l, 18 Sr, Pyp, Spl 2
17 222311 (10000000- ) Brush, Scb, 36l, 18 Sr, Nyl, Spl 2
17 222312 (10000000- ) Brush, Scb, 36l, 18 Sr, Abr, Spl 2
- Identifies an assembly
Y - Identifies parts included in assembly
